This is not some off the shelf part added to make the 95 "new and improved". The new 95 series has been under development for over two years so that this new version would live up to the name it proudly wears. MTX engineers went back to the drawing board to make the 95 Series bigger and better than the now famous 9500 version. This meant building the sub to handle more power with better materials to provide superior accuracy and cooling, while at the same time improving SPL output and sound quality from our already high standards.
General Features:
- Conservatively rated at 1500 Watts
- Cast Aluminum Basket that Reduces Resonance and Improves Sound Quality
- Inverted Apex Surround with 1.25" Xmax Maximizing SPL Output
- High Efficiency Glass Fiber Cone for accurate reproduction
- 4" Aluminum Voice Coil
- 3-Layer Thermal Management Reduces distortion at High Output
- Spider Plateau Venting Mechanical Cooling Technology
- Internal Voice Coil Heatsink
- Integrated T-Yoke Heatsink
- 8 AWG Compression Terminals
The 95 series uses a new cast aluminum basket that delivers exceptional strength in containing the oversized magnet and subwoofer motor structure as well as reducing resonance improving overall sound quality. The new Inverted Apex Surround replaces the older style high roll surround. This new surround design increases effective surface area of the cone by using half the width of the old style surround without sacrificing any excursion. In fact the new 95 has an Xmax of 1.25". Couple that incredible excursion with increased surface diameter and the result is exponentially increased SPL output.
A glass fiber cone which offers excellent stiffness to weight ratio is used to lower weght and increase sensitivity creating higher SPL using lower power. Each unit features a progressive layered spider that helps ensure linear movement of the subwoofer thereby reducing distortion. The spider also protects the integrated tinsel leads and because of its construction requires no break in period meaning the subwoofer can handle full power as soon as it is installed. The voice coil has a 4" diameter and utilizes high temperature aluminum wire designed to withstand high current over long periods of time ensuring the 95 is ready to play at all times.
A three layer thermal management design incorporates multiple means of cooling the voice coil so that it plays distortion free even at high output. Spider Plateau Venting is a mechanical cooling process that circulates hot air for cool air at the voice coil as the subwoofer continuously cycles. An integrated voice coil heatsink helps reduce voice coil temperature, dissipating it through its mass and out away from the voice coil. Finally an integrated t-yoke heat sink on the backplate absorbs heat from the voice coil and radiates it to the back of the subwoofer away from the voice coil.
- Diameter : 15 Inch
- Maximum Power : 3000 Watts
- Low Frequency Response : 17 Hz
- High Frequency Response : 100 Hz
- Sensitivity : 84.9 dB
- Frequency Response : 17-100 Hz
- RMS Power Range : 1500 Watts
- Peak Power Handling : 2000 Watts
- Top Mount Depth : 10-1/4 Inches
- Number of Voice Coils : Dual
- Product Highlights:
- 15" Dual 2 ohm 95 Series Subwoofer
- Power Handling:
- Peak: 3000 watts
- RMS: 1500 watts
- Top-mount depth: 10-1/4"
- Cutout diameter: 13-7/8"
- Frequency Response: 17 - 100Hz
- Sensitivity: 84.9 dB
- Resonance Frequency (Fs): 24
- Recommended power range: 750 - 1700 RMS
- High Efficiency Glass Fiber Cone
- Inverted Apex Surround
- Three layer thermal management design
- Internal Voice Coil Heatsink
- Cast Aluminum Basket
- 8 AWG Compression Terminals
- 4" Aluminum Voice Coil
- MAGNET
- UPC: 715442352869
- Weight: 63
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
