- 100 Watts x 2 RMS Power into 4 Ohms
- 200 Watts x 2 Max Power into 4 Ohms
- 400 Watts x 1 Power Bridged
- 180 Watts x 2 RMS Power into 2 Ohms
- Minimum Speaker Impedance: 2 Ohms
- THD: 0.1%
- S/N Ratio: >100dB
- Frequency Response: 10Hz - 30kHz (+/-3dB)
- Low Pass Filter: 50Hz~250Hz, 24dB/Octave
- High Pass Filter: 90Hz~250Hz, 24dB/Octave
- Q Bass : +18dB
- Input Sensitivity: 200mV to 8V
- Fuse Rating: 30A x 1
- Dimensions: 6.6"W x 1.7"D x 9.5"L
- Authorized Internet Dealer
*Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 30 days from the original date of purchase with proper return authorization. After the 30 day time period, products must be returned to their original manufacturer for the remainder of the manufacturer's warranty period.
Do you own this product? Write a review
Laxplayer92 From Maryland
|I just bought this amp and i have had it in my car for a day or two. I have messed with the frequency and leverl adjustments on the amp.
HU is Dual XD 6320
The two subs im running off this are Orion XTR 12 inch.
IWht 5.25 inch alpine Type-s.
IN a small cabin so it rocks it pretty well.
With this amp I can fit it in my cener console and it is 2 ohm stable. This little thing packs a punch and i have an approximate 1 inch roof flex and y dash actually flexes as well.
The way i wired it is 4 ohm stereo load which is series wiring. YOU have so many options when wiring this amp.
1) 2 ohm stereo
2)4 ohm stereo or mono
3)8 ohm mono and or stereo.
and so on. so with this small amp you get this much versitility.
I personally have it at 4 ohm stereo and the leverl at about 1/2 and the freq at about 70 to 80. There is also low pass, flat and high pass.
For this small of an amp I am so happy with its performance. Although Lanzar does put its name on some "iffy stuff" I don't think this is one of them. The opti-drive series is a good one from this amp all the way up.|
