- Low Frequency Response : 5 Hz
- High Frequency Response : 250 Hz
- Number of Channels : 1
- Built In Crossovers : Yes
- Channel Separation : Yes
- RMS Power Range : 1000-2060 Watts
- 1000 watts x 1 @ 4 ohm mono
- 1500 Watts x 1 @ 2 ohms Mono
- 2060 Watts x 1 @ 1 ohms Mono
- Dimensions: (W x H x L) 9 1/8" x 2 1/2" x 17 3/4"
- Linkable with Second Identical Model (Hardware Included)
- Hour Meter
- Remote Mount PMA100V Digital Volt Meter
- Remote Mount PMA10B Bass Boost Control
- Heavy Duty One-Piece Extruded Aluminum Heat Sink
- Beveled Clear Acrylic Protective Cover
- Tiffany-Style RCA Jacks
- Parallel Line-Out RCA Jacks
- Removable Aluminum Side Covers Conceal Control & Terminal Panels
- MOSFET High-Speed Switching Power Supply
- Milspec Double-Sided Glass Epoxy Circuit Board w/ Through-Hole Plating
- Heavy 4 oz. Pure Copper PC Traces at All Preamp & Amplification Stages
- Internally Mounted Fan-Cooled Power Supply
- Solid Brass Nickel-Plated Terminal Blocks (4-Gauge Power, 8-Gauge Speaker)
- Variable Low-Pass Filter: 50Hz - 150Hz @ 24dB/Octave
- Variable Subsonic Filter: 15Hz - 40Hz @ 24dB/Octave
- Variable Bass Boost @ 45Hz: 0 - +18dB
- Variable Phase Shift: 0 - 180°
- THD: <0.08%
- Signal-to-Noise Ratio: >100dB
- Frequency Response: 5Hz - 250Hz
- Input Impedance: 10kO
- Input Sensitivity: 300mV~8V
- 4-Way Protection Circuitry: Thermal, Short Circuit, Overload & DC Offset
- Cooling Fan
- UPC:
- Weight: 0
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
Do you own this product?
Write a review!
-
this amp is a heavy hitter
-
this amp is awesome. i have it hooked up with 4 solo baric L7 12". It slams.
-
I have got this amp pushing two RE Audio 12's wired to 1 ohm and man this amp is very strong. highly recommended
-
I have two Alpine 12" type Rs hooked up at 4ohms. This amp is definitely worth the money. The sound quality is great and it makes my subs hit hard. Only complaint is it doesn't hit the higher bass notes hard enough. Everything else is exceptional. I love the bass boost remote this amp comes with because it flashes red when your subs are reaching distortion and the volt meter it has is nice too. There's plenty of options for you to customize your bass how you like. Before this I had a Kenwood KAC-9103D (900w @ 1ohm). Big improvement.
-
I bought this amp for one sub called the mayhem made by alphasonik it hits so hard that if you were in a car in front of me and all your windows are up you can still feel my bass
-
I bought one to run on a DD 3515 in an s10 at 2ohms man this thing is great. Loaded with control and can be bought very reasonable.Highly recommended.
-
I have this amp pushing 2 15 cvrs and it's half way it's worth the money planning to put 2 solobaric 15 l7s on it that should do it
-
i have had this amp for four years now. i have 2300 hours on mine, ive blown many speakers with it, 2 mofos, 2 L5s,2 type rs, 1 alphasonik mayhem, jl w6. i win every car show i go to for loudest system, i have four sony explods now, somehow they take it when all these others didnt, this amp has overheated on me one time since ive owned it, believe me i play it hard, ive blown 3 alternators and 3 red top batteries so this amp takes the power to run but puts out just as much
-
I had this amp running two alphasonic 12's and all i gotto say is WOW!!! I was very please with this amp. It hit extremely hard and the bass was very clear as well.
