- Maximum Power : 3000 Watts
- Low Frequency Response : 10 Hz
- High Frequency Response : 240 Hz
- Number of Channels : 1
- Built In Crossovers : Yes
- Channel Separation : Yes
- RMS Power Range : 750-1500 Watts
- Competition SPL Digital Mono Amplifier with 3000 Watts Max. Power
- Peak Music Power: 3000 Watts
- Load Impedance Capability: 2~8 Ohm
- Continuous Power (4 ohm): 750W x 1
- Continuous Power (2 ohm): 1500W x 1
- Total Harmonic Distortion: 0.05%
- Signal-to-Noise Ratio: 90dB
- Bridgeable
- Class-D Design
- PWM Regulated MOSFET Power Supply
- MOSFET Output Section
- Screw-Type Speaker Terminals
- Balanced Isolator Input Circuit
- 2 Channel RCA Inputs Gold
- RCA Outputs (Pass Thru)
- Input Level Control: Hi-Volt (200mV ~ 6.5v)
- Built-in Crossover: Selectable LPF
- Dimensions: 10-3/16" x 2-1/16" x 9-13/16"
- UPC:
- Weight: 0
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
Do you own this product?
Write a review!
-
this thing is great. Not many other amps can put out this much power and mantain decent sq. I had this and a pioneer 5000spl in an excursion and it was incredible. I sold it recently and replaced it with a 13w7 and 1000/1. SQ is better than 5000spl but the 13w7 is not near as loud as the pioneer was w/ this 3000w beast hooked to it
-
I had this amp running two 12" Pioneer Premier TS-W2000SPL in a custom ported box. I had these in my 99 Grand AM GT. The hit extremely hard and sounded decent. Only complaint is that there are no fuses on the amp, they give you one to run in-line in the power cable. This proved not so well with me as the amp heated up too quickly all the time (even@only4ohms) and I eventually burnt this amp up. I switched to Alpine amps.
-
this is an outstanding amp, but only if you want spl (sound pressure level).. and you need a sub that can hit down to 10hz or else anything below what your sub is rated at will sound distorted... and you need to get a head unit that can reproduce frequencies that hit 10hz or below, or else your amp and sub wont hit it... all in all this is my amp of choice considering that i have an IDMAX sub (Which has high output, and high linear excursion), that has an RMS wattage of 1000 and a max of 1800. The frequency range is 10-250hz... i have others too but thats another story...
-
to pioneer corp.(I BEEN WAITING FOR 10 YEARS). finally an amp that not a high current but real efficeint SPL product.the only thing is high current is my alternater to help supply the rest of the electrical audio/video. I have 4 prs300412spl b'ing push from the prs5000spl in a 02 gmc denali it is awsome the only thing i would change is putting another prs5000spl amp.(CRAZY)
-
I recently bought this amp and am pushing two TS-W3004SPL subs with it. After the installation i barely turned up the head unit and all the windows and doors on the building i was next to started rattling...hell i even mad the next door neighbour about 200 ft. away kick up a storm about all the racket i was creating....all i can say is WOW!!!!
