General Features
- 6 Channel Alarm and Remote Car Starter with 5 on-board relays for parking lights, starter, accessories, ignition 1&2 and one additional relay / socket for starter disable.
- New High-Tech chrome metal finish with smart-looking leather strap for the key ring.
- New USB Rechargeable lithium Ion battery with wall charger.
- New LCD screen with 50% more viewing space includes new 7-color selectable backlighting.
- Two-way paging transceiver with 7-color LCD screen uses SST Spread Spectrum Technology for transmitting and receiving at 915 megahertz. Unit also includes 24-hour clock with meter minder, temperature, Voltage indicator and countdown run timer.
- New Design Two-way, window mount super extended range helical transceiver antenna module.
- NEW 5-button extended range METAL one way remote transmitter.
- New EMS-1 mini-size Dual Stage shock sensor
- On-board 2 way Serial Port for i-Data Link Data Bus and Bypass module integration.
- C3 compatible data port for C3 Telematics integration
- Programmable outputs, plus new starter and ignition timing sequence for improved compatibility with 2007-2010 new vehicles.
- On-board temperature and Voltage sensors for identifying in-cabin temperature and battery voltage from the LCD remote.
- New Main Unit Design with wiring harness on one side, hidden door compartment for plug-in shock sensor and V/O switch, plus on-board 30/40 ampere micro relays that contribute to 50% reduction in main unit size to fit smaller and tight spaces under the dash of newer cars.
- 5-button configuration with selectable Button Lock to prevent accidental mis-use.
- Two-car Operational
- 24-hour digital clock with count down timer for parking meter reminder. The clock doubles as a temperature indicator for monitoring in-car temperature.
- Multiple audible confirmation tones as well as vibrator mode for paging.
Alarm Features
- 6 Channels of outputs (3 dedicated to lock/unlock, trunk and remote start / 3 auxiliary output)
- Dedicated function buttons on LCD remote and 5-button standard mini-remote transmitter.
- New Turbo Timer and window Comfort Feature .
- Code learning / Anti-scan receiver with programmable code hopping.
- Back-up memory system
- Dedicated remote panic and car locator
- Passive arming by-pass from the remote
- Parking light flash with dual polarity relay on-board
- Starter disable output with relay and socket included
- Dome light illuminated entry output
- Dual polarity (+/-) door lock outputs with optional driver s door priority two step unlock
- Additional positive and negative inputs
- 500 mA grounded outputs for starter disable and door lock/unlock
- Programmable momentary, latched or timer on auxiliary channel.
- Programmable manual / passive arming with true last door arming with auto re-arm on
- Programmable Single / Double Pulse Unlock
- Programmable Parking lights (flash or constant)
- Programmable Pathway Illumination (on / off)
- Programmable voltage sense for delayed dome lights (on / off)
- Programmable horn and siren chirp delete
- Programmable ignition control lock and unlock
- Programmable pulse time for lock and unlock (.9 sec. / 3 sec.)
Remote Start Features
- 5 On-Board Relays:
- Ignition 1
- Ignition 2
- Starter
- Accessory
- Parking Light
- 3rd Ignition (-) output
- Ground when start (-) output
- Selectable one or two push Safety Start
- Programmable gasoline or diesel with 10, 15, or 20 second Wait-to-Start
- Hood pin switch safety input (pin switch included)
- Selectable RPM / Voltage Start
- RPM / Voltage / Hi-Low level check
- Timer control start option
- Sensor control output during start
- Temporary Stop Feature
- Factory Alarm Disarm and Rearm signal output
- Programmable factory keyless door locking before and after start
- Programmable start status output with shock sensor bypass
- 45 second door / dome light bypass after ignition is turned off.
- Programmable Ignition 2 (on / off)
- Programmable 3 hour timer start
- Programmable 1 / 3 hour timer start
- Selectable Run Timer (5/10/20/30 minutes)
- Ignition control by-pass during remote start
- Selectable Gasoline / diesel
- Selectable Diesel warm-up time
- Programmable Ignition control locks bypass (on / off)
- UPC: 094922111531
- Weight: 4
