- Number of Channels : 1
- Frequency Response : 10-20000 Hz
- Built In Crossovers : Yes
- Channel Separation : Yes
- RMS Power Range : 600-2200 Watts
- Amplifier Class : A/B
Power Handling:
- 600W x 1 @ 4 Ohms Mono
- 1100W x 1 @ 2 Ohms Mono
- 2200W x 1 @1 Ohm Mono
General Features:
- High Current Circuitry
- PWM MOSFET Power Supply
- Double-Sided Glass Epoxy Circuit Board
- S/N Ra tio: >100dB (+/- 1dB )
- Frequency Response: 10Hz – 20kHz
- Input Sensitivity: 200mV ~ 8V
- Variable 24dB High-pass Cross over: 50Hz – 750Hz
- Variable 24dB Low-pass Cross over: 30Hz – 120Hz
- Variable Subsonic Filter: 20Hz - 45Hz
- Variable Bass Boost: 0 – 18dB
- Variable Bass Boost Frequency: 40Hz – 100Hz
- RCA Throughput Connections
- 4-way Protection Circuitry: Thermal, Short Circuit, Overload , and DC Offset
- Dual Cooling Fans
- Digital Meter Output Response
- Cobalt Blue Illumination
- Remote Mount Bass Boost Control Knob
- High Gloss Chrome-Plated Finish
- Nickel-plated Block Terminals
- Dimensions: 11-15/16" (W) x 15-1/2" (L) x 2-1/2" (H)
- UPC: 651718015628
- Weight: 0
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
