- Maximum Power : 400 Watts
- Number of Channels : 2
- Frequency Response : 500-60000 Hz
- Built In Crossovers : Yes
- Channel Separation : Yes
- RMS Power Range : 150-200 Watts
- Amplifier Class : A/B
- Fuse Rating : 25A x 1 A
Power Output
- 75W x 2 @ 4-Ohms
- 100W x 2 @ 2-Ohms
General Features
- Pulse Width Modulated MOSFET power supply
- LED power (green) and standby/fault (red) indicators
- Variable bass EQ (0-12 dB @ 45 Hz)
- Soft Start Turn-on
- 2/1 Channel operation
- Speaker-level (high-level) inputs with signal sensing for automatic turn-on
- Preamp RCA outputs to daisy chain multiple amps
- 3-Way System Protection circuitry (thermal, DC-Offset, and speaker short protection)
- Heavy duty extruded heatsink for extreme heat dissipation
- High current bi-polar output transistors
- Optimized class AB design minimizes distortion and reduces idle current
- High pass / low pass / full range selector switch
- Chrome-plated RCA level inputs
- Chrome-plated screw terminals
- Variable High-Pass Filter (40-300 Hz, 12 dB/octave)
- Variable Low-Pass Filter (40-300 Hz, 12 dB/octave)
- Signal-to-Noise Ratio: >100 dB
- Channel Separation: >60 dB
- Frequency Response: 500-60,000 Hz
- Variable Input Level: 400mV - 5V
- THD (Total Harmonic Distortion): 0.02%
- Fuse Rating: 1 x 25 amps
- Dimensions: 9"D x 9-1/2"W x 2-1/2"H
- UPC: 043258304872
- Weight: 5
- Authorized Internet Dealer
