Power Output

• 75W x 2 @ 4-Ohms
• 100W x 2 @ 2-Ohms

General Features

• Pulse Width Modulated MOSFET power supply
• LED power (green) and standby/fault (red) indicators
• Variable bass EQ (0-12 dB @ 45 Hz)
• Soft Start Turn-on
• 2/1 Channel operation
• Speaker-level (high-level) inputs with signal sensing for automatic turn-on
• Preamp RCA outputs to daisy chain multiple amps
• 3-Way System Protection circuitry (thermal, DC-Offset, and speaker short protection)
• Heavy duty extruded heatsink for extreme heat dissipation
• High current bi-polar output transistors
• Optimized class AB design minimizes distortion and reduces idle current
• High pass / low pass / full range selector switch
• Chrome-plated RCA level inputs
• Chrome-plated screw terminals
• Variable High-Pass Filter (40-300 Hz, 12 dB/octave)
• Variable Low-Pass Filter (40-300 Hz, 12 dB/octave)
• Signal-to-Noise Ratio: >100 dB
• Channel Separation: >60 dB
• Frequency Response: 500-60,000 Hz
• Variable Input Level: 400mV - 5V
• THD (Total Harmonic Distortion): 0.02%
• Fuse Rating: 1 x 25 amps
• Dimensions: 9"D x 9-1/2"W x 2-1/2"H

• UPC: 043258304872
• Weight: 5
• Sku: Power4002
