Power Output

• 4Ω RMS Power Output: 45W x 4 Channels; 150W x 1 Channel
• 2Ω RMS Power Output: 75W x 4 Channels; 300W x 1 Channel

General Features

• Conformal Coated PCB and pre-amp prevent corrosion of key electrical components
• Splash resistant end panels protect feature controls using Plexiglass covers that prevent moisture intrusion into the amplifier chassis
• Intelligent Surface Mount Technology ensures electrical components are secured tightly to the PCB which increases the resistance to vibration
• Stainless steel screws resist corrosion and gold plated terminals ensure maximum signal and current transfer
• RCA connections have rubber gaskets surrounding them preventing moisture from entering the pre-amp or corroding the connector, rubber boots also included to cover unused RCA's

General Specifications

• Part Number: TM1805
• Topology: Class D (Sub Channel); Class A/B Full Range
• Signal-to-Noise Ratio (1Watt): 78dB FR / 70dB Sub Channel
• Frequency Response: 20Hz - 20kHz
• Maximum Input Signal: 2.5V
• Maximum Sensitivity: 200mV
• Crossover: Defeatable 18dB/octave @ 85Hz selectable HP/FR
• Bass Boost: 0-18dB Centered @ 40Hz
• Salt Spray Tested: 500 Hours ASTMB117-03
• Dimensions
  • Height: 2 3/8" (6.03 cm)
  • Width: 15 1/16" (38.26 cm)
  • Depth: 9 1/2" (24.13 cm)

• UPC: 715442241033
• Weight: 10
• Sku: TM1805
