What's Included:
- 2 End caps (installed)
- Instruction manual (English/ French/ Spanish)
- Two 30-amp fuses (installed)
- 2.5mm Allen wrench
- Four 5/8" Self-tapping screws
Product Highlights:
- mono subwoofer amplifier
- Sensitivity: 100 dB
- 500W RMS x 1 @ 2 Ohms
- Class-D amplifier design
- 10"W x 2-3/16"H x 7-3/8"D
- CEA-2006 compliant
- Variable Bass Boost
- preamp inputs
- Frequency Response: 20-200Hz
- 300 watts RMS x 1 at 4 ohms (500 watts RMS x 1 at 2 ohms)
- variable low-pass filter (50-200 Hz at 24 dB/octave)
- bass boost (0-18 dB at 40 Hz)
- frequency response: 20-200 Hz
- fuse rating: 30A x 2
- 8-gauge power and ground leads recommended — wiring and hardware not included with amplifier
- Variable High Pass Filter
- Variable Low Pass Filter
- Dimensions: 9-1/4" W x 2-3/16" H x 7-9/16" D
- 300W RMS x 1 @ 4 Ohms
- 1000W Max Power
- Maximum Power : 1000 Watts
- Number of Channels : 1
- Frequency Response : 20-200 Hz
- Built In Crossovers : Yes
- Channel Separation : No
- Amplifier Class : D
Specifications |
THD at Rated RMS Power |
1% |
High-Pass Crossover Frequency |
N/A |
Input Voltage |
14.4v |
Height (inches) |
2-3/16 |
Width (inches) |
10 |
Bass Boost Frequency |
40 Hz |
High-Pass Slope (dB/octave) |
N/A |
Fuse Rating |
60 |
Minimum Impedance Unbridged |
2 |
Fan Cooled |
No |
Power at 2 Ohms (Watts x Channels) |
500 x 1 |
Amplifier Class |
D |
Signal to Noise Ratio |
83 dB |
Low-Pass Slope (dB/octave) |
24 dB/oct |
Speaker Level Inputs |
No |
Low-Pass Crossover Frequency |
50-200 Hz |
Bass Boost |
0-18 dB |
Preamp Outputs |
No |
Depth (inches) |
7-3/8 |
RMS Power Output (Watts x Channels) |
300 x 1 |
Peak Power Output (Watts x Channels) |
N/A |
Bridged Power (Watts x Channels) |
N/A |
Minimum Impedance Bridged |
N/A |
Best Frequency Response |
20-200 Hz |
- UPC: 019048197566
- Weight: 5
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
Do you own this product?
Write a review!
-
this amp is tiny but has to put out more than 600 rms,have it pushing the newest rockford p3 15d4 and it makes that sub dance,cant believe such a small amp can be this badass. Its turned up 3/4 gain and half boost and the sub cant handle anymore power,and the output sounds real clean.this amp is a steal at this price,,,highly reccomend
-
For the money and size this amp is a beast, i dont even have it turned up halfway and my subs still slam
