- Diameter : 6.5 (approx) Inch
- Sensitivity : 88 dB
- Impedance : 4 Ohm
- Frequency Response : 29-25000 Hz
- RMS Power Range : 50 Watts
- Peak Power Handling : 280 Watts
- Design : 3 Way
Power Handling
Product Features
- Injection molded polypropylene cone - A lighter, thinner yet more rigid cone material.
- Large magnet assembly - High efficiency output, high power handling.
- Silk dome tweeters - Very accurate, high frequency response tweeters.
- FFFT ferro fluid filled tweeters - High heat dissipation - greater reliability.
- Multi-Fit Basket
Product Specifications
- Basket - Steel Frame
- Cone Material - IMPP
- Frequency Response - 29Hz-25kHz
- Peak Power (Watts) - 250
- Rated Power (Watts) - 45
- Protection Boot - Yes
- Sensitivity (dB) - 88
- Surround Material - PU
Thiele Small Parameters
- Compliance (Cms) (?M/N) - 671.187
- Cone Area (Sd) (cm²) - 113
- D.C. Coil Resistance (Re) (Ohm) - 3.2
- Diaphragm Mass (Mmd) (Kg) - 0.00106
- Electrical Q (Qes) - 0.633
- Force Factor (Bl) (TM) - 4.557
- Free Air Resonance (Fs) - 57.755
- Mechanical Q (Qms) - 3.881
- Total Loudspeaker Q (Qts) - 0.544
- VAS (CuFt) - 0.430
- VAS (L) - 12.17
- Voice Coil Impedance - 4 Ohm
Mounting Dimensions
- Mounting Depth 2-9/16"
- Mounting Diameter 5-5/32"
- UPC: 878816005874
- Weight: 6.1
