- Diameter : 12 Inch
- Sensitivity : 89 dB
- Impedance : 4 Ohm
- Frequency Response : 24-1000 Hz
- RMS Power Range : 325 Watts
- Peak Power Handling : 1300 Watts
- Number of Voice Coils : Single
Power Handling
Product Features
- Dish Cone Technology - Accurate sound dispersion. Reduced break up distortion.
- Woven heavy duty fabien leads - Vastly improved reliability. Maximum current delivery.
- Heavy Duty Push Terminals - For simple, easy installation. Maximum current delivery.
- Max Voice Coil venting - Improved thermal transfer - greater reliability. High Power handling.
Product Specifications
- Cone Material - Pressed Paper
- Frequency Response 24Hz - 1kHz
- Peak Power (Watts) - 1,300
- Rated Power (Watts) - 325
- Sensitivity (dB) - 89
Thiele Small Parameters
- Compliance (Cms) (?M/N) - 113.913u M/N
- Cone Area (Sd) (cm²) - 531.000
- D.C. Coil Resistance (Re) (?) - 3.900 Ohm
- Electrical Q (Qes) - 0.676
- Force Factor (Bl) (TM) - 14.277
- Mechanical Q (Qms) - 6.055
- Total Loudspeaker Q (Qts) - 0.608
- Voice Coil Impedance - 4 Ohm
Mounting Dimensions
- Mounting Depth 6-1/16”
- Mounting Diameter 10-15/16”
- Outside Diameter 12-17/32"
- UPC: 878816005935
- Weight: 15
