Fusion :: CSSW100 :: $55.00

Fusion CSSW100

Item# 33544

10" 800W Car Subwoofer


Sorry, this product is no longer available.

Power Handling

  • 200W RMS
  • 800W Max

Product Features

  • Dish Cone Technology - Accurate sound dispersion. Reduced break up distortion.
  • Woven heavy duty fabien leads - Vastly improved reliability. Maximum current delivery.
  • Heavy Duty Push Terminals - For simple, easy installation. Maximum current delivery.
  • Max Voice Coil venting - Improved thermal transfer - greater reliability. High Power handling.

Product Specifications

  • Cone Material - Pressed Paper
  • Frequency Response 33Hz - 1.2kHz
  • Sensitivity (dB) - 87

Thiele Small Parameters

  • Compliance (Cms) (?M/N) 271.431u M/N
  • Cone Area (Sd) (cm²) 356.000
  • D.C. Coil Resistance (Re) (?) 3.900 Ohm
  • Electrical Q (Qes) 0.493
  • Force Factor (Bl) (TM) 12.703
  • Mechanical Q (Qms) 7.376
  • Total Loudspeaker Q (Qts) 0.462
  • Voice Coil Impedance 4 Ohm

Mounting Dimensions

  • Mounting Depth   4-23/32”
  • Mounting Diameter  9"
  • Outside Diameter  10-19/32"
  • Subwoofers are usually sold as a single unit unless otherwise noted.
  • UPC: 878816006024
  • Weight: 9.5
