Chauvet ColoradoBatQuad-9ip Item# 34540
Colorado Batten Quad-9 IP - Compact Washlight with 9 Colored LEDsĀ
Chauvet :: ColoradoBatQuad-9ip :: $1,149.99
MSRP: $1,699.99
You Save: $550.00 (32%)
Our Price: $1,149.99
 Protect Your Investment (- hide options)

CPS Extended Service Plan (more info)




Condition: Brand New Avg Rating: Not Rated Yet
Free Shipping On This Item
magnifying glass

Please roll over the image to see detail.
Hint: click on the image to see larger image.

Features

General Features:

  • DMX Channels: 3, 4, 5, 6, 9, 11, 16, 27, or 36
  • 16-bit dimming of individual colors as well as master dimmer
  • RGBW Quad color LEDs
  • Electronic dimming
  • RGBW color mixing without control
  • Recall custom programs over DMX
  • Five distinct DIM curves
  • LED display with password protection
  • 5-pin DMX to IP connector
  • IP65
  • Glare shield included

Specifications:

  • DMX Channels: 3, 4, 5, 6, 9, 11, 16, 27, or 36
  • DMX Connectors: 5-pin
  • Light Source: 9 (Quad RGBW) 10W (800mA) LEDs 50,000hrs
  • Strobe Rate: 0 - 20Hz
  • PWM Frequency: #Hz
  • Beam Angle: 17° (Horizontally)
  • Field Angle: 31° (Horizontally)
  • Beam Angle: 15° (Vertically)
  • Field Angle: 30° (Vertically)
  • Illuminance: 1,026 lux @ 5m
  • Color Temperature Range: 2,800 – 10,000K
  • IP Rating: IP66
  • Startup Temperature: -4° - 113°F (-20°C - 45°C)
  • Operating Temperature: -22° - 113°F (-30°C - 45°C)
  • Cable Length: 5ft (1.5m)
  • Power Linking: 9 units @ 120V; 14 units @ 208V; 15 units @ 230V
  • Input Voltage: Auto-ranging 100 - 240VAC 50/60Hz
  • Power and Current: 181W, 1.51A @ 120V 60Hz
  • Power and Current: 200W, 0.96A @ 208V 60Hz
  • Power and Current: 206W, 0.90A @ 230V 50Hz
  • Weight: 25.2lbs (11.4kg)
  • Size: 39.4 x 7.9 x 9.9in (1,000 x 200 x 250mm)
  • Approvals: CE, MET
  • Authorized Internet Dealer
*Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 30 days from the original date of purchase with proper return authorization. After the 30 day time period, products must be returned to their original manufacturer for the remainder of the manufacturer's warranty period.
