- Maximum Power : 640 Watts
- Number of Channels : 4
- Frequency Response : 20-23000 Hz
- Built In Crossovers : Yes
- Channel Separation : Yes
Power Handling:
- 50W RMS x 4 @ 4 Ohms
- 75W RMS x 4 @ 2 Ohms
- 150W x 2 [Bridged] @ 4 Ohms
- 160W x 4 (MAX Power)
General Features:
- LED power (green) and protect (red) indicators
- Variable Bass Boost (0 to +12 dB bass boost at 50 Hz)
- Soft start turn-on
- Gain LED indicators for proper gain adjustment
- 4/3/2 channel operation
- Heavy duty aluminum alloy heat-sink
- Nickel-plated RCA level inputs
- Nickel-plated screw terminals
- Low level: 125mV-5V
- High level: 250mV-10V
- Variable low-pass filter (40-220 Hz, 24 dB/octave)
- Variable high-pass filter (40-220 Hz, 24 dB/octave)
- CEA-2006 compliant amplifier
- Frequency response: 20-23000 Hz
- 8 gauge power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier.
- Dimensions: 9-11/16"W x 8-3/8"L x 2-9/16"H
- UPC:
- Weight: 0
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
Do you own this product?
Write a review!
-
Sounds great with my JBL speakers. Easy to install.
