Monoblock Class D Marine Subwoofer Amplifier 1000W

MSRP:$739.99
Regular Price:$729.99
Savings Of:$110.00
Your Price $629.99

FREE Shipping in US 48!

vehicle fit guide

This potent monoblock subwoofer amplifier employs our high-speed NexD™ switching design to achieve unprecedented efficiency and amazing power output in a very compact chassis.

The M1000/1v2 is capable of delivering 1000 W of continuous power into a 2 ohm load (14.4V, 1% THD), making it a great choice to drive higher power subwoofer systems. Designed specifically for subwoofer applications, the M1000/1 includes a variable slope low-pass filter with continuously variable cutoff frequency selection from 50-500 Hz and a defeatable infrasonic filter (30 Hz, 24 dB/oct.). With the addition of an HD-RLC remote level control (sold separately), the amplifier's subwoofer output level or master volume for all channels can be directly controlled from the helm.

The M1000/1v2 also features the v2 Spec feature set, which consists of automatic turn-on capability (via signal sensing or DC-offset sensing), and a dual-range differential-balanced input section able to handle a wide range of input voltage levels. This amplifier features white and gray powder-coat finish, a gasketed cover for the controls and stainless steel hardware for durability in the marine environment.

General Features:

  • Monoblock Class D Marine Subwoofer Amplifier
  • RMS Power Rating @ 14.4 V:
  • 4 ohms: 600 watts x 1 chan.
  • 3 ohms: 800 watts x 1 chan.
  • 2 ohms: 1000 watts x 1 chan.
  • 1 ohms: N/A
  • RMS Power Rating @ 12.5 V:
  • 4 ohms: 500 watts x 1 chan.
  • 3 ohms: 650 watts x 1 chan.
  • 2 ohms: 800 watts x 1 chan.
  • 1 ohms: N/A
  • Input Voltage Range (Selectable):
  • Low level: 200 mV - 2 V RMS
  • High level: 800 mV - 8 V RMS
  • Frequency Response: 7 - 500 Hz (+0, -1dB)
  • Total Harmonic Distortion (THD): <1.0% @ 2 Ω per channel
  • Signal to Noise Ration: >83 dB
  • Damping Factory @ 4ohms: >1000 / 50 Hz
  • Variable low-pass filter: 50 - 500 Hz, 12 or 24 dB/octave
  • Selectable Subsonic (Infrasonic) Filter: Off / 30 Hz
  • Recommended Inline-Fuse Rating (not included): 80 A x 1 (AFS, AGU or MaxiFuse™)
  • 4 gauge OFC power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier.
  • Dimensions: 7.09"W x 14.73"L x 2.05"H
  • Unregulated MOSFET switching type
  • NexD™ ultra-high-speed switching design
  • Selectable turn-on modes
  • +12V remote turn-on lead (preferred method)
  • DC Offset-Sensing: detects a very small DC signal (high level signals)
  • Signal sensing: detects presence of a full-range audio signal
  • Dual-Range Differential Balanced Input Section
  • RCA inputs accept Speaker-Level Inputs or Line-Level signals
  • JL Audio XD-CLRAIC2-SW required for speaker level, sold separately
  • LED power (green) and protect (red) indicators
  • 3-way protection circuitry (thermal, overload, and speaker short protection)
  • Heavy duty aluminum alloy heat-sink for extreme heat dissipation
  • White and gray powder-coat finish
  • Gasketed covered controls and stainless steel hardware
  • Detented, Calibrated Filter Freq. Potentiometer
  • Wired remote level control available, sold separately: JL Audio HD-RLC
  • Product Highlights:
  • Monoblock Class D Marine Subwoofer Amplifier
  • RMS Power Rating @ 14.4 V:
  • 4 ohms: 600 watts x 1 chan.
  • 3 ohms: 800 watts x 1 chan.
  • 2 ohms: 1000 watts x 1 chan.
  • 1 ohms: N/A
  • RMS Power Rating @ 12.5 V:
  • 4 ohms: 500 watts x 1 chan.
  • 3 ohms: 650 watts x 1 chan.
  • 2 ohms: 800 watts x 1 chan.
  • 1 ohms: N/A
  • Input Voltage Range (Selectable):
  • Low level: 200 mV - 2 V RMS
  • High level: 800 mV - 8 V RMS
  • Frequency Response: 7 - 500 Hz (+0, -1dB)
  • Total Harmonic Distortion (THD): <1.0% @ 2 Ω per channel
  • Signal to Noise Ration: >83 dB
  • Damping Factory @ 4ohms: >1000 / 50 Hz
  • Variable low-pass filter: 50 - 500 Hz, 12 or 24 dB/octave
  • Selectable Subsonic (Infrasonic) Filter: Off / 30 Hz
  • Recommended Inline-Fuse Rating (not included): 80 A x 1 (AFS, AGU or MaxiFuse™)
  • 4 gauge OFC power and ground wiring is required for installation. Contact us for information regarding a discount on select amplifier kits from our website when purchased together with this amplifier.
  • UPC: 699440983570
  • Weight: 9
  • Sku: 98357
