Pioneer TS-Z10LS2 10" 400W RMS Single 2 Ohm Voice Coil Car Subwoofer
We are a Pioneer authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- •One 10" Shallow mount subwoofer
- •Six 1-1/8" Self-tapping screws
- •Rubber gasket (installed)
- •Warranty information
- •Owner's Manual
Elevate Your Audio Experience with the Z Subwoofer's Unrivaled Bass Mastery
Derived from the advanced Z full range loudspeakers, the Z subwoofer embodies unmatched musical excellence – delivering swift, detailed, extended bass with remarkable impact and clarity. Its compact, shallow design achieves high fidelity and output, providing boundless installation options for optimal sound quality and bass reinforcement. Experience the ultimate blend of balance, speed, power, and bass extension – your gateway to low-frequency nirvana.
Unveiling Sub-Bass Brilliance
Hi-Res Audio recordings hold notably more data in the sub-bass area than standard CDs, demanding a subwoofer of exceptional dynamic range and low distortion. Z subwoofers excel in harnessing Hi-Res Audio's full potential, delivering precise, detailed bass that seamlessly integrates with mid- and high-frequency speakers.
Redefining Subwoofer Performance with the Z Series
Subwoofers demand a robust basket, ensuring alignment during low-frequency excursions. Conventional ones need large enclosures, posing installation challenges. The Z subwoofer offers a shallow basket, high performance in small enclosures, an oversized cone (15% larger than a standard 10" subwoofer), and a potent 67.7 oz. magnet. These elements create swift, detailed, extended bass with impactful clarity.
Elevate Your Sound with Twaron Strength and Precision in Z Series
Twaron, a synthetic aramid fiber, when woven into cloth, offers remarkable strength, heat resistance, and rigidity. Twaron-based subwoofer cones, with low mass and strong damping, ensure cone integrity during intense bass notes. This enhances responsiveness and signal accuracy, crucial for optimal performance. The lightweight aramid fiber boosts sensitivity and speed in the Z subwoofer, amplifying output and power handling.
- Diameter : 10 Inch
- Sensitivity : 80 dB
- Impedance : 2 Ohm
- Frequency Response : 20-3800 Hz
- Peak Power Handling : 1300 Watts
- Top Mount Depth : 3-1/4 Inches
- Shallow Mount : Yes
- Number of Voice Coils : Single
- Suggested Sealed Box Volume : 0.6 Cubic ft.
- Suggested Ported Box Volume : 0.6 Cubic ft.
- RMS Power Handling : 400 Watts
- Free Air : Yes
Features:
- Twaron® Aramid Fiber + Cellulose Fiber Dual Layer Cone Construction
- Extended Voice Coil, Dual Spider Design for Increased Linearity and High Excursion
- Shallow Basket, Small Enclosure Design for Sound Optimization and Installation Flexibility
- Designed for Hi-Res Audio
Specifications:
KEY FEATURES
- System Type: Component Subwoofer
- Sensitivity (1W/1m): 74 dB
- Frequency Range: 20 Hz to 3.8 kHz
- Hi-Res Certified: Yes
- CTA-2031 Compliant: Yes
- Warranty: 1 Year
- Continuous Power handling (RMS): 400 Watts
- Maximum Peak Power Handling: 1300 Watts
- Nominal Impedance: 2 Ohms
BUILD
- Shape: Round
- Size: 10" oversized
- Cone Material: IMPP - Composite
- Drive Cone Material: Twaron Aramid Fiber
- Surround Material: Rubber
- Surround Type: Rolled
- Basket Material: Die Cast Aluminum
- Magnet Material: Ferrite
- Magnet Weight: 70.2 oz
- Voice Coil Type: Single Voice
- Voice Coil Bobbin: Glass imide
- Voice Coil wire: Copper
- Damper: Poly cotton
- Gasket: Rubber
- Wire Terminals: Push Type
- Unit Size (Dimensions): 11-1/8"
- Mounting Depth: 3-1/4"
- Cut Out dimensions: 9-1/8"
- Equivalent Compliance (VAS) [L]: 23.1
- Free Air Resonance (Fs) [Hz]: 34
- Total Speaker "Q" (Qts): 0.48
- Linear Excursion (Xmax) [mm]: 9.4
- Recommended Sealed Box Volume [L]: 17
- Port Box volume [L]: 17
- Port Length: 7-1/2"
- Port Diameter: 3"
- UPC: 884938374552
- Weight: 14
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
