- Maximum Power : 1600 Watts
- Low Frequency Response : 50-250 Hz
- Number of Channels : 4
- Frequency Response : 50-250 Hz
- Built In Crossovers : Yes
- RMS Power Output : 300x4 Watts
- Channel Separation : Yes
- Amplifier Class : A/B
General Specs
-
CHANNEL CONFIGURATION: 4/3/2 Channel
-
POWER SUPPLY TYPE: MOSFET Power Supply
-
AMP TOPOLOGY: Full Range, Class A/B
Performance Specs
-
TOTAL POWER OUTPUT: 1600 Watts
-
PEAK POWER @ 2-ohms: 400 Watts x 4
-
PEAK POWER @ 4-ohms: 200 Watts x 4
-
RMS POWER @ 2-ohms: 450 Watts x 2
-
RMS POWER @ 4-ohms: 150 Watts x 4
-
BRIDGED POWER @ 4-ohms: 800 Watts x 2
-
BRIDGED RMS POWER @ 4-ohms: 600 Watts x 3
-
SPEAKER IMPEDANCE 2 to 8 ohms
-
FREQUENCY RESPONSE: 50HZ TO 250HZ
Connections, Controls, and Processing
-
RCA INPUTS: 2 Channel
-
PRE AMP OUTPUTS 2 CHANNEL
-
HIGH LEVEL INPUTS: YES
-
LOW PASS FILTER: 50HZ TO 250HZ
-
BASS BOOST: Variable 0 to 18dB
-
SUBWOOFER LEVEL CONTROL: YES
-
INPUT SENSITIVITY SWITCH: YES
-
THERMAL/OVERLOAD/SHORT PROTECTION: YES
Measurement
-
WIDTH: 7"
-
LENGTH: 12.25"
-
HEIGHT: 2.3"
- UPC: 791489125857
- Weight: 10
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
