What's Included:
- Owner's Manual
- Specifications printed on box
- Two 12" Lengths of speaker wire (each has quick-slides on one end and bare wire on the other)
- 8 Speed clips
- Two 2-way speakers
- Eight 3/4" Self-tapping screws
Product Highlights:
- 1-3/16" PET dome tweeter
- top-mount depth: 1-3/4"
- power range: 2-35 watts RMS (250 watts peak power)
- frequency range: 34-25,000 Hz
- 5-1/4" polypropylene woofer cone
- 2-way car speakers (pair)
- sensitivity: 86 dB
- impedance: 4 ohms
- Diameter : 5.25 Inch
- Sensitivity : 86 dB
- Impedance : 4 Ohm
- Frequency Response : 34-25000 Hz
- RMS Power Range : 35 Watts
- Peak Power Handling : 250 Watts
- Design : 2 Way
- Top Mount Depth : 1-3/4 Inches
- Woofer Composition : IMPP
- Tweeter Composition : PET
The TS-G1345R speakers are excellent choices to replace a bad set of factory 5-1/4" speakers. Their two-way design handles 250 watts max. power (35 watts nominal) and feature Pioneer’s extremely strong and lightweight Injected Molded Polypropylene™ (IMPP) Composite Cone Woofer, for improved sensitivity and reduced distortion. You don't get just basic, run-of-the-mill features either. The conex damper delivers higher power handling and deeper bass, and the 1-3/16” Piezoelectric tweeter reproduces highs with great performance and musicality. These speakers are designed with a shallow mounting depth for easy install into a wide variety of vehicles. Speaker grilles are not included.
Specifications |
Tweeter Design |
1-3/16" Balanced Dome |
RMS Power Range (Watts) |
2-35 |
Sensitivity |
86 dB at 1 watt |
Tweeter Composition |
PET |
Woofer Composition |
IMPP |
Bottom-mount Depth (Inches) |
N/A |
Design |
2-way |
Woofer Surround |
Cloth |
Frequency Response |
34 - 25k Hz |
Peak Power Handling (Watts) |
250 |
Impedance (Ohms) |
4 |
Top-mount Depth (Inches) |
1 3/4 |
Cutout Diameter or Length (inches) |
4 3/8 |
- UPC: 884938265805
- Weight: 30.4
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
