- Rated Power @ 14.4V
- 75W RMS x 4 @ 4 ohms
- 100W RMS x 4 @ 2 ohms
- 150W RMS x 2 [Bridged] @ 8 ohms
- 200W RMS x 2 [Bridged] @ 4 ohms
- Rated Power @ 12.5V
- 60W RMS x 4 @ 4 ohms
- 90W RMS x 4 @ 2 ohms
- 120W RMS x 2 [Bridged] @ 8 ohms
- 180W RMS x 2 [Bridged] @ 4 ohms
- 12dB/octave Butterworth filter alignment
- Selectable High-Pass or Low-Pass modes for each channel pair
- Fully-variable frequency selection from 50-500 Hz
- Fully-defeatable for use with external crossovers
- Inputs: Two Stereo Pairs (RCA-Type Jacks), Differential-Balanced Inputs
- On-board Crossover: State-variable, 12dB/octave Butterworth with continuously variable cutoff frequency selection from 50-500 Hz. Configurable as Low-Pass or High-Pass. Defeatable.
- Speaker output connections: Accept up to 12 AWG wire
- +12V and Ground connections: Accept up to 4 AWG wire
- Cutting-edge NexD Class D switching technology reduces distortion and delivers exceptional efficiency
- Active Crossover Features fully variable 12dB/octave filters with detented filter frequency selection controls offer excellent tuning flexibility.
- Borrowing a page from the HD amplifiers' bag of tricks, the XD amplifiers employ advanced thermal and low-impedance protection to virtually eliminate annoying amplifier shut-down events
- Pass-through pre-amp outputs permit interconnection of multiple amplifiers
- Differential-Balanced Inputs greatly reduce noise and provide compatibility with a wide range of sources, including most OEM systems.
- With the addition of an HD-RLC you can control the overall level of the amplifier (or amplifiers) from the front of your vehicle.
- THD at Rated Power: <1% THD+Noise (20Hz - 20 kHz)
- S/N Ratio:
- >104 dB referred to rated power (A-weighted, 20 Hz-20 kHz noise bandwidth)
- >84 dB referred to 1W (A-weighted, 20 Hz-20 kHz noise bandwidth)
- Frequency Response: 12 Hz - 22 kHz (+0, -1dB)
- Damping Factor:
- >150 @ 4 ohms per ch./ 50 Hz
- >75 @ 2 ohms per ch. / 50 Hz
- Input Range: 100mV - 4V RMS
- Dimensions (L x W x H): 8.52" x 7.09" x 2.05"
