Alpine MRX-V60 Item# 29155

1200W 5-Channel Class-D (Digital) MRX Series Power Amplifier

Alpine :: MRX-V60 :: $289.00
MSRP: $399.95
Regular Price: $399.95
You Save: $110.95 (27%)
Our Price: $289.00
 Protect Your Investment (- hide options)

CPS Extended Service Plan (more info)
Condition: Brand New Avg Rating: Not Rated Yet
Free Shipping On This Item
magnifying glass

Please roll over the image to see detail.
Hint: click on the image to see larger image.

Features

Power Output @ 14.4V %THD+N
  • 50W x 4 @ 4-Ohms
  • 75W x 4 @ 2-Ohms
  • 150W x 2 @ 4-Ohms
  • Mono Channel: 200 x 1
General Features
  • Amplifier Type: Class-D (Digital)
  • Channel Design: 4 Channel + Subwoofer
  • Thermal Control: Thermal Management Control
  • Power Supply: MOSFET
  • Power Supply Design: DC-DC PWM Power Supply
  • Board Circuitry: S.T.A.R. Circuitry
  • Current Protection: Over-Current, Over-Voltage and Thermal Protection
  • Power Indicator: Top Mounted Blue LED Power Indicator
  • Speaker-Level Inputs: Speaker Level Inputs
  • Crossover: Variable Lowpass & Hiighpass Filter
  • Final Outputs: Direct FET
  • Board Design: 6-layer Glass Epoxy PC Board
  • Gain Control: Continuously Adjustable Gain Control
  • Bass Control: Remote Bass Control (Sold separately)
  • Power Requirements: 14.4V DC (11V to 16V)
  • Input Sensitivity (RCA Input): 0.2 - 4.0V
  • Input Sensitivity (Speaker Level Input): 0.5 - 10V
  • Frequency Response (+0, -3dB: 1W into 4 Ohms) for CH-1/2/3/4: 5 -45Hz
  • Frequency Response (+0, -3dB: 1W into 4 Ohms) for Subwoofer: 5 -400Hz
  • Frequency Response (+0, -1dB: 1W into 4 Ohms) for CH-1/2/3/4: 7 -30Hz
  • Frequency Response (+0, -1dB: 1W into 4 Ohms) for Subwoofer: 10 -300Hz
  • THD+N (10W into 4 Ohms) for CH-1/2/3/4: 0.02%
  • THD+N (10W into 4 Ohms) for Subwoofer: 0.008%
  • THD+N (Rated Power into 4 Ohms) for CH-1/2/3/4: 0.07%
  • THD+N (Rated Power into 4 Ohms) for Subwoofer: 0.04%
  • Damping Factor for CH-1/2/3/4: i?z500
  • Damping Factor for Subwoofer: i?z1000
  • Signal to Noise (Rated Power into 4 Ohms) for CH-1/2/3/4: 104dB
  • Signal to Noise (Rated Power into 4 Ohms) for Subwoofer: 110dB
  • Remote Level: 0 to -20dB (RUX-KNOB Required)
  • Dimensions: 10-5/8''W x 2-1/4''H x 9''D
    *Warranty: 1 Year Onlinecarstereo.com warranty.
    1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
