SOUND OPTIMIZATION
From advanced technologies that enable playback of premium High-Resolution Audio sources, to the vast array of sound adjustment functions to fine-tune and customize the acoustics exactly the way you want — count on JVC to deliver the music to your ears.
- Maximum Power : 200 Watts
- CD-R/CD-RW Compatible : Yes
- CD Text : Yes
- Remote Control : Yes
- RMS Power Output : 88 Watts
- Built-in EQ : Yes
- DIN : 2
- Display Size : 6.8 Inch
- Bluetooth : Yes
- Aux Input : Yes
- MP3 Playback : Yes
- WMA Playback : Yes
- Rear USB Input : 1
Monitor
- Screen Size: 6.8" Wide VGA
- Touch Panel: Clear Resistive
- Monitor Touch Control: Yes
- Customizable GUI: Yes
- Key Illumination Color: White
- Dimmer: Yes
- Multilingual Display: Yes[4]
- Wallpaper Capture: Yes
Media Playback
- MP3 Compatible with Tag: USB
- WMA Compatible with Tag: USB
- WAV Compatible with Tag: USB
- AAC Compatible with Tag: USB
- FLAC Compatible with Tag: USB
- DSD Compatible with Tag: USB
- H.264 Compatible: USB
- WMV Compatible: USB
- MPEG 1/2 Compatible: USB
- MPEG 4 Compatible: USB
- AVI/MKV Compatible: USB
Bluetooth Control
- Built-in Bluetooth[1]: Yes (Version 3.0, Wired-Mic included)
- Hands Free Call: Yes (HFP1.6 Wideband Speech)
- 2 Phones Full-Time Connection: Yes
- Audio Streaming & Control (A2DP, AVRCP): Yes
- Voice Dialing (voice recognition compatible mobile phone required): Yes
- Phone Book Access Profile (PBAP): Yes
- Alphabetical Search for Phone Book: Yes
- Auto Pairing for iPhone/Android: Yes (iPhone only)
Android Control
- Android Auto[2]: Yes
- Pandora Control: Yes (via Bluetooth(R))
- Spotify Control: Yes (via Bluetooth(R))
iPod/iPhone Control
- CarPlay[3]: Yes (USB)
- iPod/iPhone Music Playback: Yes (via USB or Bluetooth(R))
- Pandora Control: Yes (via USB or Bluetooth(R))
- Spotify Control: Yes (via USB or Bluetooth(R))
USB
- USB Port: x2 (High Speed)
- Position: Rear (Cable Detachable)
- USB Power Supply: Yes (1.5A High Current Charging)
- Drive Change Mode for Mass Storage Class (selectable from internal/external memory): Yes
Radio Tuner
- SiriusXM Ready: Ready (SXV100/200/300 required)
- Radio Broadcast Data System (RBDS): Yes
- Digital Processing Tuner: Yes
- Preset Stations: 20 (FM:15ch, AM:5ch)
- Automatic Presetting (Strong Station Sequential Memory): Yes
Audio
- Maximum Power Output (Front & Rear): 50W x 4
- Full Bandwidth Power (Front & Rear): 22W x 4 (Full Bandwidth Power, at less than 1% THD)
- MOS-FET Amplifier: Yes
- EQ: Yes (13-Band Graphic EQ)
- Preset EQ: Yes (8Preset + 4user)
- Bass Boost: Yes
- High-Pass Filter/Low-Pass Filter: Yes/Yes
- 3-Way X'over: Yes
- High-Resolution Audio: Yes
- K2 Technology: Yes
- Space Enhancement: Yes
- Sound Response: Yes
- Sound Lift: Yes
- Volume Link EQ: Yes
- Time Alignment: Yes
- Dual-Zone Function: Yes
Inputs and Outputs
- AV Input: mini jack
- Video Out: RCA
- Second Audio Output Terminals: Yes
- Rear view camera Input: Yes
- Line Output Terminals (pair): 3 Pairs (Front + Rear + Subwoofer)
- Pre-output Level/Impedance: 4.0V / 10k ohms
- Subwoofer Output with Level/Frequency Control: Yes
General
- Back Up Memory: Yes
- Viewing Angle Adjustment: Yes (0 - 20 degree, default : 0 degree) 4steps
- Wireless Remote Control Ready (RM-RK258 required)
- Steering Remote Control Ready: Yes
- iDatalink Maestro Ready: Yes
Dimensions (W x H x D)
- Installation Size: 7-1/16" x 3-15/16" x 6-2/16" (178 x 100 x 155 mm)
- Weight, inlcuding sleeve and escutcheon: 3.75 lbs. (1.7kg)
- Unit weight in individual package: 5.95 lbs. (2.7kg)
- UPC: 46838075223
- Weight: 6.39
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
