- 3-Band Parametric Equalizer
- 6 Factory Presets (Flat/Rock/Pop/Vocal/Jazz/Soft)
- 4 User Presets
- Nuance Control
- Auto-EQ - Auto Frequency Response Calibration System
- 3 Curves Available (Dynamic/Natural/Mild)
- Omni-Directional Microphone (Included)
- DSP Mode (Sound Field Priority)
- 5-Mode Digital Sound Field Control (SFC) (Studio, Jazz Club, Concert, Club, Stadium)
- Listening Position Selector (4 Mode: Front Left/Front Right/Front/All)
- Front & Rear HPF: 50/80/125/200Hz, Level -24 to 0dB, Slope -12/-6/0dB
- Subwoofer LPF: 50/63/80/100/125/160/200Hz, Level -24 to +6dB, Slope -18/-12/-6dB
- Phase Switch for Subwoofer
- Pro Mode (Digital Network Priority)
- Time Alignment (0 ~ 160", 0.5" Steps)
- Listening Position Selector (4 Mode: Front Left/Front Right/Front/All)
- High HPF: 2.5k/3.15k/4k/5k/6.3k/8k/10kHz, Level -24 to 0dB, Slope -18/-12/-6dB
- Mid LPF: 2.5k/3.15k/4k/5k/6.3k/8k/10kHz
- Mid HPF: 40/50/63/80/125/160Hz, Level -24 to +0dB, Slope -18/-12/-6dB
- Low LPF: 40/50/63/80/125/160Hz, Level -24 to +6dB, Slope -24/-18/-12dB
- Phase Switch for High/Mid/Low
- Free-Space Controller/Display with Compact Hide-Away Sub-Chassis for Easy Installation
- 8fs 1-Bit Legato Link D/A Converter
- Multicolor Display with EL Backlighting
- Detachable Face Security (with Carry Case)
- RCA Input
- RCA Outputs (x3 Pair) (Front/Rear + Subwoofer or High/Mid/Low)
- Remote Control Sensor for Optional Remote
- Super Capacity 3-Day Backup for DSP Memory
- Dimensions (WxHxD): 7-3/8" x 2-1/4" x 1-1/4"
- UPC:
- Weight: 0
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
Do you own this product?
Write a review!
-
this unit is great with any head unit, there are two different settings on the brain with PRO and STD. you can make a delay time between each speaker,also you can use the graphic or parametric EQ or you can use them both at the same time with up to 8 different sound fields. so many features i cant possibly tell you all of them. you gotta check this unit out, i use it with a clarion DVX935DV player, and a audiobahn 12" woofer, and 8" full range, 6x9, 4ch audiobahn amp, 2 ch audiobahn amp. WOW!
-
A versitile unit that has a number of good features and can be added to any aftermarket system.
Has a few restrictions, in that it will only accept 2 volt in which doesn't allow many of todays 4 volt + headunit to operate at the peak. It also only has 500mv output meaning you will need sensitive amplifiers to use this effecitvely.
Handy features include, time correction, eq with memory settings and spectrum analyser.
Also has good crossover and adjustment settings, although not fully flexible as far as frequency adjustment goes.
-
I use thjs unit, long time, with 2 10" sony subs, 4 6x9 pionner speakears 400.4 rockford fosgate amp and pionner 25w 2 channel amplifier, and sounds greate, very versatil it can be set as you like it, auto equalizer works excelent.
-
