- Low Frequency Response : 20 Hz
- High Frequency Response : 5000 Hz
- Number of Channels : 4
- Built In Crossovers : Yes
- RMS Power Range : 120-240 Watts
30W x 4 Channels: @ 4 Ohms
60W x 4 Channels: @ 2 Ohms
120W x 2 Channel: @ 4 Ohms Bridged
Power Bandwidth: 7Hz to 80kHz
Signal to Noise Ratio: 105 dB
Total Harmonic Distortion: .05%
Input Sensitivity: 100mV to 12V
Input Impedance: 10k Ohms
Load Impedance (Stereo): 2 Ohms to 8 Ohms
Load Impedance (Bridge): 4 Ohms to 8 Ohms
Supply Voltage: 10V to 15V
Damping Factor: >300
Slew Rate: >45V/µs
- UPC:
- Weight: 0
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
Do you own this product?
Write a review!
-
I have this Amp in my 2002 silverado with two of the channels bridged to power one 10" kicker in a small sealed box. its a great add on to a stock system and would be even better if i had another 10" sub since there are 2 more extra channels. i am impressed with the amount of bass that only comes from one 10" with 120 watts RMS powering it (at 2 Ohms).
i am looking to upgrade my system and looking to use this amp to power some pioneer component speakers in my doors as opposed to using an aftermarket head unit.
this is an old, but quality amp.
