- 500W RMS x 1 @ 4-Ohms
- 1000W RMS x 1 @ 2-Ohms
- 12dB/octave crossover
- 4 Gauge power/ground connections with built-in ATC fusing
- MOSFET power supply
- RCA pass-thru
- Efficiency (average): 90% @ 4-Ohm, 89% @ 2-Ohm
- Crossover Controls: Low Pass (LP): 40Hz-130Hz @ 12dB/octave Butterworth
- Tone Controls: Punch Bass: 0dB to +12dB @ 45Hz
- Signal Input: Low Level: 1 RCA pair
- Signal Output: Low Level: 1 RCA pair
- Power Input Connector: Screw terminal barrier strip
- Power Wire Gauge: 4 AWG
- Speaker Output Connector: Screw terminal barrier strip
- Speaker Wire Gauge: 8 AWG
- Heat Sink Type: Extruded Aluminum
- Cooling: Convection
- Remote Controls: Punch Level Control (when connected, is linked to "gain control" to provide remote output level)
- Visual Indicators: Power, Protect
- Circuit Topology Class: Class D
- Frequency Response: 20Hz to 130Hz +/-1dB
*Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warranted against being blown, burned or abused.
