AudioControl EQX - $219.95
 Item# 25220 / Condition:  Brand New

AudioControl EQX

EQX
2-Channel Pre-Amp Equalizer & Crossover with Speaker Level Review this product
$219.95

FREE Shipping in US 48!

MSRP:$399.99
Regular Price:$389.99
Savings Of:$180.04
Add Extended Warranty
  • comments
  • email
  • Facebook
  • Twitter
  • Print

Related Video:


coming_soon

What's Included:


  • Power and Speaker Connector
  • Manual
  • EQX

Product Highlights:


  • 13 volt line driver
  • Balanced inputs
  • 6 bands of 1/2 octave bass equalization
  • Programmable Frequency Match (PFM) Filter Switchable ground isolation
  • Dual bandwidth equalization with crossover
  • 7 band octave equalizer
  • 24dB/octave Linkwitz-Riley alignment crossover
  • High pass, low pass and full range outputs plus mono/invert sub output
  • Line level/speaker level inputs
  • Input/output level matching

The EQX is a 2 channel trunk-mount equalizer with crossover. The Dual bandwidth equalization with crossover comes built into the equalizer. Six bands of 1/2 octave bass equalization provide a smooth performance. Also standard is a 7 band octave equalizer. The crossover is a 24dB/octave Linkwitz-Riley alignment. The equalizer also has high pass, low pass and full range outputs plus mono/invert sub output. A Programmable Frequency Match (PFM) Subsonic Filter is built into the amplifier. The two channel dual bandwidth equalizer includes switchable ground isolation. The equalizer includes Line level/Speaker level inputs. The 2 channel trunk-mount equalizer with crossover also has Input/output level matching. Balanced differential inputs are built into the equalizer. The EQX comes with a 13 volt line driver. There is 1 Preamp Input Channel built into the equalizer. The input gain registers 18dB. It has a Maximum Input Level of 7.5 Vrms. There is 1 Speaker Level input built in. The EQX has 1 Speaker Level Input. The EQX has 1 Preamp Output. It has a Maximum Output Level of 7.5 Vrms. The equalizer has a 24dB/octave Linkwitz-Riley crossover type. The Total Harmonic Distortion is 0.005%. The Frequency Response registers 10 Hz - 20kHz. It has a Signal to Noise ratio of 110dB at full output. The recommended Fuse Rating is 2A. The dimensions are as follows: 8.9″W x 6.9″D x 1.25″H. It has a weight of 2.7 lbs.



Specifications
Remote In Power Supply: Variable Isolation Transformer Switching Supply
Frequency Response: 10Hz-20kHz 1 dB
Maximum Output Level: 7.5Vrms
Crossover Type: 24dB/octave Linkwitz-Riley
Preamp Outputs: 1 (2 channels)
Speaker Level Inputs: 1 (2 channels)
Preamp Inputs: 1 (2 channels)
Total Harmonic Distortion: 0.005%
Input Gain: 18dB
Signal to Noise: 110dB at full output
Recommended Fuse Rating: 2A
Dimensions: 8.9W x 6.9D x 1.25H
Weight: 2.7lbs (1.2kg)
  • UPC: 855814005822
  • Weight: 3
*Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warranted against being blown, burned or abused.
