- Low Frequency Response : 50 Hz
- High Frequency Response : 50000 Hz
- Number of Channels : 4
- Built In Crossovers : Yes
- Channel Separation : Yes
- RMS Power Range : 400-600 Watts
- RATED OUTPUT POWER (14.4V):
- 100W RMS x 4 @ 4 Ohms
- (20Hz-20kHz @ 0.05%THD)
- 150W RMS x 4 @ 2 Ohms
- (1kHz @ 0.5% THD)
- 300W RMS x 2 @ 2 Ohms (Bridged)
- (1kHz @ 0.5% THD)
- RMS POWER OUTPUT (CEA-2006)
- 100W RMS x 4
- (RMS @ 4 Ohms, 1% THD+N)
- 85dBa Signal-To-Noise Ratio
- BUILT-IN CROSSOVER CONTROL:
- Variable High-Pass Filter: 50Hz-200Hz (-12dB/oct)
- Variable Low-Pass Filter: 50Hz-200Hz (-12dB/oct)
- TERMINALS:
- Battery: Hex Type (4 AWG)
- Ground: Hex Type (4 AWG)
- Speaker: Hex Type (8 AWG)
- Operating Voltage: 14.4V
- Current Consumption: 64A
- S/N Ratio: 105dB
- Frequency Response: 5Hz-50kHz
- Input Sensitivity: 0.2V ~ 5.0V
- Installation Size:
- Width: 14-15/16"(380mm)
- Height: 2-5/8"(66mm)
- Depth: 11-1/4"(286mm)
- Weight: 10.8 lbs. (4.9Kg)
- UPC:
- Weight: 0
