Power Output:

• 500W RMS x 1-Channel @ 4 Ohms
• 1000W RMS x 1-Channel @ 2 Ohms

General Features

• High-Efficiency Class-D Design in most monoblock amps
• KickEQ™ Boost with variable gain up to 18dB centered at 40Hz
• Active 50-200Hz variable 12dB/octave XOVER with selectable HiPass, LoPass, or AllPass capability on full-range channels
• Active 50-200Hz variable 24dB/octave LoPass XOVER on mono channels
• Automatic turn-on options include: 12 volt remote turn-on, DC offset, and audio signal sensing
• Differential Hi- and Lo-Level Inputs for integration in any system
• Advanced protection circuitry: low/high voltage, over-current, and thermal protection with indication on end panel
• All feature FIT™ Fail-Safe Integration Technology with advanced input design
• FIT accepts output from virtually any source unit – factory or aftermarket – low signal-level to high speaker-level
• FIT's isolated inputs reject electrical interference for noise-free operation
• FIT's three turn-on modes interface with virtually any vehicle's electrical system
• Bass Remote Included

General Specifications:

• Frequency Response: 25-200Hz, +0/-1dB
• Input Sensitivity: High Level 250mV-10V, Low Level 125mV-5V
• Signal-to-Noise Ratio: >95dB, a-weighted, re: rated power
• Active Crossover: 24dB/octave, variable 50Hz-200Hz, low pass only
• 24dB/octave high-pass subsonic filter fixed @ 25Hz
• KICKEQ™ Boost: Variable to +18dB, centered @ 40Hz
• Height: 2-1/8"
• Width: 9-5/8"
• Depth: 16-3/4"

• Sku: 11ZX10001
