- High Frequency Response : 20-20000 Hz
- Number of Channels : 4
- Frequency Response : Yes Hz
- Built In Crossovers : Yes
- Channel Separation : Yes
- RMS Power Range : 220-360 Watts
- Amplifier Class : A/B
RMS Power Rating (@ 14.4V):
-
- 70W x 4 @ 4-Ohms
- 90W x 4 @ 4-Ohms
- 180W x 2 [Bridged] @ 4-Ohms
RMS Power Rating (@ 12.5V):
-
- RMS Power Rating (@ 12.5V):
- 55W x 4 @ 4-Ohms
- 80W x 4 @ 4-Ohms
- 160W x 2 [Bridged] @ 4-Ohms
General Features
- Unregulated PWM switching type power supply
- LED power (green) and protect (red) indicators
- Soft start turn-on prevent clicking and popping when system turns on
- 4/3/2 channel operation
- Speaker-level (high-level) inputs with signal sensing for automatic turn-on
- Preamp RCA outputs to daisy chain multiple amps
- 3-Way System Protection circuitry (thermal, low impedance, and speaker short protection)
- Heavy duty aluminum alloy heatsink for effective heat dissipation
- Nickel-plated RCA level inputs
- Nickel-plated screw terminals
- Variable low-pass filter (50-200 Hz, 12 dB/octave)
- Damping factor: >60 @ 4 ohm
- Frequency response: 20-20,000 Hz (+/– 1 dB)
- Recommended Fuse Value (Type): 50A (MAXI or AGU)
- Dimensions: 15-1/2"L x 7-3/4"W x 2-1/8"H
- UPC: 699440993951
- Weight: 10
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
Do you own this product?
Write a review!
-
Wow I have this amp in my dodge avenger 2008 pushing 4/6.5 american bass mids 300 watts each and also I have 2 db p5tw 7d tweeters in dash and is incredible the sound by this toy I recommended this amp for the money you pay.
Also ihave a 12w7 whit jl 500/1 and the sound is perfect
THANK YOU JL AUDIO FOR THE PRODUCTS YOU MAKE....
-
This is a good price online have seen some stores wanting 250 to 300 it's not worth that.This amplifiers applause nothing below 70htz in my set up so I've never seen it get hot that's probably the best thing doesn't get hot and reliability but That's what jl is all about
-
This amp was perfect for what I needed it for. Plus it was a great price and shipping was incredibly fast for where I live. (Alaska) will definitely buy from here again
-
Let me start by saying Wow. Price, delivery, quality..AMAZING! Very satisfied. I will recommend will shop again!
-
Wow another great product from JL AUDIO this amp make your mids to the point you enjoy your music I got this amp in my car and i had no "problems" I recommend this amp to everyone looks for a quality amp..... tnx jl for all this great products
