What's Included:
- 2 JBL logo badges
- Instruction manual
- Eight 1-3/8" Self-tapping Allen head screws
- 3mm Allen head bit
- 2 Bottom mount adapters
- 2 Adhesive backed foam gasket strips
- 2 Grilles
- Two 3-way speakers
- 8 Speed clips
Product Highlights:
- sensitivity: 94 dB
- edge-driven silk dome tweeter and supertweeter with adjustable tweeter level
- carbon-injected Plus One™ woofer cone with butyl rubber surround
- 6"x9" 3-way speakers (pair)
- power range: 5-100 watts RMS (300 watts peak power)
- impedance: 3 ohms
- frequency response: 46-21,000 Hz
- top-mount depth: 2-13/16"
- grilles included
- Diameter : 6x9 Inch
- Sensitivity : 94 dB
- Impedance : 3 Ohm
- Frequency Response : 46-21k Hz
- RMS Power Range : 100ea Watts
- Peak Power Handling : 300ea Watts
- Design : 3 Way
- Top Mount Depth : 2-13/16 Inches
- Bottom Mount Depth : 3-1/2 Inches
- Woofer Composition : Carbon Composite
- Tweeter Composition : Cloth
- Shallow Mount : Yes
JBL® GTO Series high-fidelity automotive speakers feature innovative technologies that we’ve engineered for the environment and conditions in today’s cars to help them deliver exceptional sound. Using patented, carbon-injected Plus One® (U.S patent no. 7,548,631) woofer cones, fiberglass-reinforced plastic (FRP) frames, butyl rubber surrounds and fabric tweeter diaphragms, GTO Series automotive speakers are the ideal upgrade to any car’s audio system.
GTO Series speakers, including component separates with woofer, tweeter and passive crossover, cover the most popular factory-replacement and aftermarket sizes. Other unique features such as UniPivot™ (U.S. patent no. 6,002,780) tweeter positioning and tweeter level controls on select coaxial models or the I-Mount™ (U.S. patent no. 5,859,917) system for the tweeters in the component separates provide even greater installation flexibility to achieve the ultimate in-vehicle sound experience.
Easily installed and built to last, JBL GTO Series speakers bring music to life in the car.
Specifications |
Top-mount Depth (Inches) |
2 7/8 |
Sensitivity at 2.83 volts |
94 |
Bottom-mount Depth (Inches) |
3 9/16 |
Tweeter Composition |
Silk |
Minimum RMS Wattage |
5 |
Peak Power Handling (Watts) |
300 |
Design |
3-way |
Tweeter Design |
Edge-Driven Dome |
Maximum RMS Wattage |
100 |
Speaker Size |
6X9 |
Woofer Composition |
Carbon-injected |
Woofer Surround |
Butyl Rubber |
Sensitivity (1W at 1 meter) |
N/A |
Frequency Response |
46 - 21k Hz |
Impedance (Ohms) |
3 |
- UPC: 050036313773
- Weight: 11
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
