What's Included:
- One 15" Dual 4-ohm voice coil subwoofer
- Manual (English/ Spanish/ German/ French)
- Kicker logo sticker
- Template on box
- Product Information Inside Box
- 2 Units of 43CVR154
Product Highlights:
- frequency response: 25-500 Hz
- sensitivity: 89.2 dB
- injection-molded polypropylene cone
- 15" subwoofer with dual 4-ohm voice coils
- ribbed Santoprene rubber surround
- power handling: 100-500 watts RMS (250 watts per coil)
- 1,000 watts peak power handling
- top-mount depth: 8-3/16"
- sealed box volume: 1.8-5.2 cu. ft.
- ported box volume: 3.0-5.0 cu. ft.
- Diameter : 15 Inch
- Maximum Power : 1000 Watts
- Low Frequency Response : 25 Hz
- High Frequency Response : 500 Hz
- Sensitivity : 89.2 dB
- Impedance : 4 Ohm
- Frequency Response : 25 - 500 Hz
- RMS Power Range : 250 - 550 Watts
- Top Mount Depth : 8 3/16 Inches
- Number of Voice Coils : dual
- Suggested Sealed Box Volume : 1.8-5.2 Cubic ft.
- Suggested Ported Box Volume : 3.0-5.0 Cubic ft.
- Mounting Depth : 8-3/16, 20.7 Inches
The CompVR 15-Inch Subwoofer is a 4Ω dual voice coil design, built for easy wiring. A solid pole piece and perimeter venting allows superb heat dissipation without breakdown and improved bass response.
The Santoprene surround and progressive-roll spider keep the cone response smooth, linear and accurate at any volume level. Sub provides 500 watts of RMS/1000 watts of Peak Power with a frequency response of 250- 500 Hz. Everything thats included is to give you the maximum experience.
The CompVR 15-Inch Subwoofer works best with a sealed or ported enclosure and 500 watts of recommended power. See below for more details.
Specifications |
Cone Material |
Polypropylene |
Cutout Diameter or Length (inches) |
13 11/16 |
Top Mount Depth (inches) |
8 3/16 |
Free-Air |
No |
Vas (liters) |
143.82 |
Fs (Hz) |
24.6 |
Frequency Response |
25 - 500 Hz |
Size |
15 -inch |
Sensitivity |
89.2 dB at 1 watt |
Dual Voice Coil |
Yes |
Peak Power Handling (Watts) |
1000 |
Impedance |
4 ohms |
Surround Material |
Rubber |
Ideal Sealed Box Volume (cubic feet) |
1.8-5.2 cu. ft. |
Ideal Ported Box Volume (cubic feet) |
3.0-5.0 cu. ft. |
Qts |
0.381 |
Xmax (millimeters) |
15 |
- UPC: 713034050056
- Weight: 54
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
