Since the beginning, Orion has been all about High Performance Car Audio and Hardcore Attitude… Attitude that is being hammered into the DNA of every piece of industrial-strength Orion Car Audio equipment, and the players that use and abuse it, the bass heads and boulevard bullies who will testify that the baddest car and the loudest system ride on the same chassis – theirs!! SPL competitors, world champions, hot rodders, urban cruisers and the ones that just want to have fun alike are motivated to roll with the bullet proof performance and legendary muscle that is Orion Car Audio.
- Diameter : 10 Inch
- Maximum Power : 4000 Watts
- Sensitivity : 84 dB
- Impedance : 4 Ohm
- RMS Power Range : 2000 Watts
- Peak Power Handling : 3000 Watts
- Shallow Mount : No
- Number of Voice Coils : Dual
Power Handling
General Features
- 4” copper Wound Voice Coil on an Aluminum Former, High temperature PAARC (Polyester Amide, Amide Resin Coated)
- Continuous power handling will be 1500W (under rated)
- X-Max estimated at 30mm (total travel 4” peak to peak)
- Field Replaceable Cone / Voice coil / Spider Assembly
- Dual Flat Conex Spiders with Loop/Stitched Tinsel Leads
- Tall, wide, balanced, Foam (high density expanded polyester foam) surround for linear controlled long excursion using a Tri-Radius symmetrical edge design optimized on non-linear FEA
- Enhanced voice coil cooling system (forced convection – aluminum heat sinking – shorting rings to reduce inductive heating)
- Dimensions (in) 9.7 x 8.7
- UPC: 093207061462
- Weight: 50
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
Do you own this product?
Write a review!
-
seriously, orion is the best. i just got rid of my old xtr to get this and it is unbelievable. i have a quantum 3000 watt amp running 1500 watts to it at 2 ohms and 32 Hz in a ported box and it is ridiculous how loud it is. it also has good sound quality. my buddy has a jl 10w7 and mine is way louder than his but still doesn't have the sound quality of the w7. i hope to get another one soon.
-
i just got this sub and it is amazing..loudness and sound quality.. i have it in a 1.3 cubic feet box at 33 hz that i built on a 2000 watt hifonics amp
-
YESSIR Orion is the best! i have one 10" runnin on a 1500rms clarion perfectly matched and i only have settings set to 1/2... till i make a custom box and get a second one :)but my one 10" orion in my JL W7 box! was louder then my buddies 2 alpine 15 type R's :) :P dont hate! :P
-
i have to of these in a 94 blazer and there alright lol just playin they are the loudest 10s i got them hooked up to a 2500 fusion with 0gauge and a 2500hc kinetik battery and 250a fuse holder and it moves the front window if you have the money i would get thesee but they are hard to power them bc im not even close i need the rockford power t4 amp to do that but i dont have 1500 dollars
