- Diameter : 5x7/6x8 Inch
- Sensitivity : 92 dB
- Frequency Response : 42-22000 Hz
- Peak Power Handling : 200 Watts
General Features
- PCT Component Mid Carbon Reinforced High Denier Woven Glass Cone
- Filleted Butyl Rubber Surround
- Aluminum Billet Phase Plug
- High Temperature Kapton Voice Coil
- Former with Nomex Insulation – 25mm
- Oversized Flat Spider
- Bottomless Motor Geometry
- Proprietary High Gauge Steel Frame with Chrome-Plated Back Plate and Magnet Cover
- PTS28 — Pure Silk Dome Tweeter in a Threaded Machined Aluminum Housing — 28mmPCT Component Crossover
- Linkwitz-Riley Alignment with Zobel Impedance Compensation
- Audiophile-Grade Mylar Caps and Air Core Inductors
- Gold-Plated, Solid Brass Compression Terminals (up to 12-Gauge)
General Specifications
- PCT 6x8 Component Mid-Bass w/ Carbon
- Reinforced Woven Glass Cone
- PTS28 - 28mm Silk Dome Tweeter
- PCT 2-Way Component Crossover
- Power Handling: 200 Watts RMS
- Frequency Response: 42Hz – 22kHz, +/-3dB
- Sensitivity: 92dB 1w/1m
- UPC:
- Weight: 0
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
