- Diameter : 6.5 (approx) Inch
- Sensitivity : 91 dB
- Frequency Response : 40-22000 Hz
- RMS Power Range : 120 Watts
- Peak Power Handling : 280 Watts
Product Features
- Titanium tweeters - Very accurate high frequency response. Critical detail and extra crisp highs.
- FFFT ferro fluid filled tweeters - High heat dissipation - greater reliability.
- CURV cone material - Light-weight yet high tensile strength and stiffness.
- Large magnet assembly - High efficiency output, high power handling.
Product Specifications
- Cone Material CURV
- Frequency Response 40Hz-22kHz
- Peak Power (Watts) - 280
- Rated Power (Watts) - 120
- Sensitivity (dB) - 91
Thiele Small Parameters
- Compliance (Cms) (?M/N) - 582.45
- Cone Area (Sd) (cm²) - 128.68
- D.C. Coil Resistance (Re) (Ohm) - 3.2
- Electrical Q (Qes) - 0.495
- Force Factor (Bl) (TM) - 5.418
- Free Air Resonance (Fs) - 60
- Mechanical Q (Qms) - 2.989
- Total Loudspeaker Q (Qts) - 0.425
- Voice Coil Impedance - 4 Ohm
Mounting Dimensions
- Mounting Depth 2.6"
- Mounting Diameter 5.5"
- UPC: 878816004990
- Weight: 11
