Series II woofers delivers the enhanced efficiency and higher output. A switch on the input terminal allows you to easily change the woofer's impedance between 2Ω and 4Ω settings.JBL uses progressive spiders to provide the best possible control at the excursion limits versus much more commonly used linear spiders.
JBL S2-1224 Owner's Manual| Specifications | |
|---|---|
| Fs (Hz) | 31.9 |
| Frequency Response | 25 - 175 Hz |
| Port length (inches) | 11.7 |
| Cutout Diameter or Length (inches) | 11 1/4 |
| Ideal Ported Box Volume (cubic feet) | 2.5 |
| Xmax (millimeters) | 10.25 |
| Surround Material | NBR |
| Vas (liters) | 61.2 |
| Cone Material | Polypropylene |
| Ideal Sealed Box Volume (cubic feet) | 0.75 |
| Free-Air | Yes |
| Port diameter (inches) | 4 |
| Size | 12 -inch |
| Qts | 0.52 |
| Impedance | 2 ohms |
| Dual Voice Coil | No |
| Sensitivity | 93 dB at 2.83 volts |
| RMS Power Range (Watts) | --- |
| Peak Power Handling (Watts) | 1100 |
| Top Mount Depth (inches) | 6 1/2 |
| Bottom Mount Depth (inches) | N/A |
Series II woofers delivers the enhanced efficiency and higher output. A switch on the input terminal allows you to easily change the woofer's impedance between 2Ω and 4Ω settings.JBL uses progressive spiders to provide the best possible control at the excursion limits versus much more commonly used linear spiders.
