This super Car Audio Subwoofer features an Inverted Apex Surround that increases surface area and Xmax allowing for increased volume displacement and higher SPL as well as a progressive, layered spider that eliminates break in time and lowers distortion resulting in improved sound quality.
This subwoofer has a dual layer thermal management system that incorporates Spider Plateau Venting, a mechanical cooling process that targets cool air at the voice coil, and an integrated t-yoke heatsink that helps eliminate excess temperature for long term performance. The glass fiber cone offers excellent stiffness to weight ratio providing outstanding sensitivity.
General Features:
- Inverted Apex Surround Increases Surface Area Resulting in Increased Volume Displacement and SPL.
- 2.5" Aluminum Voice Coil
- Spider Plateau Venting Targets Cool Air at Voice Coil for Improved Thermal Performance
- Radial, Ribbed T-Yoke Helps Dissipates Heat to Help Improve Sound Quality by Reducing Distortion
- Layered, Progressive Spider Requires No Break In Period
- Cast Aluminum Basket Reduces Resonance for Improved Sound Quality
- Features:
- Inverted Apex Surround Increases Surface Area Resulting in Increased Volume Displacement and SPL
- 2.5" Aluminum Voice Coil
- Spider Plateau Venting Targets Cool Air at Voice Coil for Improved Thermal Performance
- Radial, Ribbed T-Yoke Helps Dissipates Heat to Help Improve Sound Quality by Reducing Distortion
- Layered Spider Requires No Break In Period
- Cast Aluminum Basket Reduces Resonance for Improved Sound Quality
- Diameter : 12 Inch
- Sensitivity : 88 dB
- Impedance : 4 Ohm
- Frequency Response : 25-150 Hz
- Peak Power Handling : 1000 Watts
- Shallow Mount : No Inch
- Number of Voice Coils : Dual
- Suggested Sealed Box Volume : 1.25 Cubic ft.
- Suggested Ported Box Volume : 2.0 Cubic ft.
- RMS Power Handling : 500 Watts
Product Highlights:
- 12" Dual 4 ohm TR75 Thunder Round Series Subwoofer
- Power Handling:
- Peak: 1000 watts
- RMS: 500 watts
- Impedance: Dual 4 ohm
- Flat progressive spider
- Extended pole piece for smooth, linear, piston like drive
- Exclusive spider plateau venting cooling system
- 2.4" High temperature dual 4 ohm voice coil
- 93oz. Magnet
- Sensitivity: 88 dB
- Polypropylene cone woofer
- Stitched NBR surround
- Die-cast, stamped aluminum basket
- 8-gauge nickel compression terminals
- Rubber magnet boot
- ALDS (Asymmetrical Linear Drive System)
- UPC: 715442351817
- Weight: 24
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
