General
- FinishBlack
- Power Output; Watts Per Channel105
- All Channels Rated @ 0.08 THD
- Weight: 24.9 lbs
- Dimensions: 17.1 W x 6.7 H x 14.9 D
Sound Modes (THX Ultra2-Certified)
- dts ES Discrete 6.1 Decoding
- dts ES Matrix 6.1 Decoding
- dts Neo:6 Stereo-to-Surround Cinema and Music Modes
- dts 96/24 5.1 for DVD-Video Processing
- Audio Signal Delay (Sync. Audio with Video signal) – By source
- Pure Direct/Direct/Stereo Modes on Digital/Analog inputs
- Stereo/Direct Modes w/Pure Analog Path
- Video Game Mode
- Wide Screen 7.1 Mode
- Mono Movie Surround Mode
- Rock Arena Surround Mode
- Matrix Surround Mode
- Jazz Club Surround Mode
- Virtual Surround Mode – For 2 Speakers/Headphones
- Multi-Channel Stereo Mode: 5/6/7
- DSP Effect Modes: 7
- Auto Surround Mode (Analog or Digital Input Type)
- Active Center Channel In All Surround Modes
Connectivity
- True 24-bit/96-kHz Digital Input Capability
- Assignable Digital Inputs: 5
- Digital Inputs: Coaxial 2
- Digital Inputs: Optical 3 (Incl. Front)
- Digital Outputs: Optical 1
- Analog Audio Inputs, Including Tuner: 9 Including Sirius Radio
- Phono Input
- Source Function Renaming
- Analog Record Outputs: 2
- Front Panel A/V Inputs w/Cover: Composite and S-Video
- Video Conversion –Composite to S-Video to Component
- deo Conversion – Analog to HDMI
- Composite Video Inputs: 4 Incl. Front
- Composite Video Outputs: 2 Incl. Monitor
- S-Video Inputs: 3 Incl. Front
- S-Video Outputs: 2 Incl. Monitor
- Component Video Inputs x Bandwidth -Assignable: 2 x 60 MHz
- Component Video Outputs: 1
- 8-Ch. External Analog Input
- Banana Plug Speaker Terminals, All Channels
- Cinema EQ
- 56 Station Auto-Preset Memory Tuning
- Sirius Ready
- Direct Function (Tone Bypass)
- Volume Control Un-muting
- Selectable Muting Levels (Full/-40/-20)
- Video Select Control
- IR Serial Remote In/Out terminals
- Multi-Source/Multi-Zone (*Uses REC OUT): 2S/2Z
- Pre-amp Outputs for Multi-Zone
- High Pass Filter for Multi-Zone Outputs
- Multi-Zone Pre-Amp Outputs – Selectable Output Levels
- Discrete Remote Power On/Off, Source Selection and Volume for Main and Second/Third* Zones
- Assignable Amplifier Configuration of Surround Back Channels
- Speaker Time-Delay and Level Controls: L/R, Sub, C, Surr. L/R, Surround Back
- Pre-Amp Outputs: Sub
- iPod Dock Control Port (Using optional ASD-1R Denon iDock): ASD-1R/11R/3N/3W
- Input Delete Function
- Video Conversion Analog to HDMI Scaling 480p 720p 1080i 1080p
- HDMI 1.3a Inputs: 5 with 7.1 Uncompressed 24/96 Audio
- HDMI 1.3a Outputs: 1
- HDMI Audio/Video Repeater Function
- HDMI Deep Color Support-36Bit
- HDMI xvYCC Color Space Support
- Enhanced Power Amp Assignment
Component Technology
- Equal Power Amplifiers: Y/7 ch
- Low Impedance Drive Capability
- High-Current/Discrete Amplifiers
- Independent Power Supplies
- 24-bit/192-kHz DACs - Analog Devices: 24-bit/192-kHz ADAU1328
- Analog-to-Digital Conversion - Bit Depth/Sampling Rate: 24-bit/96-kHz
- Variable High/Low Pass Crossover Points (12/24dB) 40/60/80/100/120/150/200/250
- Built In Time Based Correction
- Automatic Lip Sync
Convenience Features
- Front Panel A/B Speaker Selector
- Auto Setup Calibration
- Auto/Manual Room Equalization
- Audyssey MultEQ
- Audyssey Dynamic Volume
- Auto Setup Microphone Included/Type: Y/Mold DM-A409
- Front Panel System Setup Control
- Personal Memory Plus
- System Setup/Surround Parameters Lockout
- Relay-Controlled Protection Circuits
- Microprocessor User Re-set: Y/p.68
- Detachable Power Cord
- Pre-programmed (10 Devices) Glow Key Remote Control with Punch Through Commands: Y/RC-1117
- Audyssey Mult EQ Room Correction Positions: 6
- GUI Menu Support
- UPC:
- Weight: 0
