Autotek  ATS693

ATS Series 6x9" 300W Peak Power Handling, 4-Ohms, 3-Way Coaxial Car Speakers

Item #37055

Product Highlights

  • ATS Series 6x9"
  • 300W Peak Power
  • 4-Ohms
  • 3-Way Coaxial
  • Car Speakers

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Sorry, this product is no longer available.
Checkout other products listed below

Huge Saving on Other items:


Available alternative products:


Huge Saving on Other items:


Autotek Banner

Autotek ATS693 - ATS Series 6x9" 300W Peak Power Handling, 4-Ohms, 3-Way Coaxial Car Speakers


We are an Autotek authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
Surround / Cone Coupling

UV Resistant Rubber Surround: Moisture Resistant Rubber Surround with high Mid-Bass Impact. High Temperature Adhesive: The cone/surround connection utilizes a high temp adhesive which assure the cone and surround do not separate in high power uses or extremes of weather.

Crossover

Passive Butterworth: Smooth transition of frequencies from midrange/midbass to the tweeter element. 6dB Internal: Integrated into the design to assure smooth midrange to tweeter frequency transitions.


SPECIFICATIONS


  • Diameter : 6x9 Inch
  • Sensitivity : 89 dB
  • Impedance : 4 Ohm
  • Frequency Response : 46-20000 Hz
  • Peak Power Handling : 300 Watts
  • Design : 3 Way
  • RMS Power Handling : 120 Watts

FEATURES


Features:

  • Tweeters: 1 inch, clear highs, handles plenty of power without sounding harsh.
  • Cone Material: Silver Alpha-Cellulose Poly Cones, produces musical midrange and bass tones while remaining lightweight.
  • Surround / Cone Coupling: UV Resistant Rubber Surround, moisture-resistant with high Mid-Bass Impact. High Temperature Adhesive ensures a secure cone/surround connection even in high-power uses or extreme weather conditions.
  • Gasket: Textured ABS, assures a ridged linear seal to the mounting surface.
  • Voice Coil / Former Assembly: Pure Copper creates a strong magnetic field with a thin extrusion. Kapton is lightweight and efficiently dissipates heat.
  • Spider: Epoxy infused Natural Fiber allows flexibility while providing strength during the manufacturing process.
  • Cooling System: Over-Coil design allows air exchange over the voice coil through the spider.
  • Crossover: Passive Butterworth ensures smooth transition of frequencies from midrange/midbass to the tweeter element. 6dB Internal integrated into the design assures smooth midrange to tweeter frequency transitions.
  • Tweeter Hardware: Neo-Mylar Soft Dome Tweeter, impact-resistant with great sound quality and increased reliability. Kapton is lightweight and efficiently dissipates heat.
  • Frame: Anti-Resonant Stamped Steel Basket, very strong with minimal harmonics or distortions from flex or ringing.
  • Motor: Ferrite Magnet creates a strong magnetic field while remaining small enough to fit nearly every application.
  • Connectors: Use spade connectors or solder direct for the best connection.
  • Grills: Yes, protects the speaker from accidental damage. Not used if the speaker is mounted behind a vehicle panel.



Specifications:

  • Weight: 6.15 lbs
  • Type: Speaker
  • Brand: Autotek
  • Series: ATS
  • Category: Mobile
  • Condition: New
  • Color: Black
  • CEA Standards: CEA426B
  • Compatible Vehicles: Universal
  • Speaker RMS Power Handling (watts): 200
  • Speaker Peak Power Handling (watts): 400
  • Speaker Impedance (ohms): 4 Ohm
  • Speaker Sensitivity: 88dB
  • Speaker Crossover Slope: 1kHz + 3kHz 12dB
  • Speaker Mounting Diameter / Cut Out (in): 8.64 x 5.98
  • Speaker Outside Diameter (in): 10.35 x 7.20
  • Speaker Mounting Depth / Chassis Depth (in): 3.35
  • Speaker Size (in): 6 x 9



  • UPC: 806576222262
  • Weight: 6
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
