Rockford Fosgate  PM1000X5

Punch Marine Series 5-Channel 1000W Max Power 2 Ohms Class A/B + Class B/D Car Amplifier

Item #41908

Condition:   Brand New

Product Highlights

  • Punch Marine Series
  • 5-Channel Amplifier
  • 1000W Max Power
  • 2 Ohms
  • Class A/B + Class B/D

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
CYBER WEEK DEALS!
Save 5% on Marine Amplifiers!

Use Code: CYBW5

Ends in:

$799.99

Reg. Price $899.99  Save $100.00
Add Extended Warranty
  Free 2-Years Warranty Included!

No Credit needed for acima logoLearn More

Rockford Fosgate Authorized Dealer

Huge Saving on Other items:


Huge Saving on Other items:


Rockford Fosgate Banner

Rockford Fosgate PM1000X5 Punch Marine Series 125W x 4 RMS + 300W x 1 RMS @ 2Ohms, 1000 Watts Class A/B + Class BD 5-Channel Amplifier


We are a Rockford Fosgate authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • 5-Channel marine amplifier
  • • 2.5mm Allen wrench
  • • (4) 1-1/2" Self-tapping screws
  • • Certificate of Performance Verification
  • • Setup guide
  • • User's Manual
5-Channel Marine Amplifier

Rockford Fosgate designed their PM1000X5 5-channel amp to be the center of your high-performance marine or powersports audio system. Run your dash speakers off the front channels, run a pair of stern-mount speakers off the rear channels and run your marine subwoofer(s) off the fifth channel. The PM1000X5 delivers plenty of power efficiently, with Class AB technology handling the front and rear channels, plus Class BD for the sub channel. It's the ideal combination of performance and precision, plus it's built for the demands of boating and off-roading.

Easy to Install and Built Tough

Life on the water or in the dirt can be hard on electronics, so the PM1000X5 is built tough. Conformal-coated circuitry withstands moisture and dirt, while the stainless steel hardware won't succumb to corrosion. Rockford Fosgate also uses the innovative Maximum Efficiency Heat Sink Application (MEHSA3) construction process, which yields up to five times better heat transfer than traditional mounting techniques. As a result, this amp will rock out without overheating, even when tucked into a tight space. And you won't have to worry about cranking it up for long periods, thanks to tri-stage protection that covers thermal, over-current and short circuits.

CLEAN Technology

The PM1000X5 uses Rockford Fosgate's CLEAN level setting technology, so there's no more guesswork while setting your gain levels. Easy-to-see LED indicators identify clipping so you can set your amp up for maximum performance while eliminating distortion.


SPECIFICATIONS


  • Maximum Power : 1000 Watts
  • Low Frequency Response : 50-250 Hz
  • High Frequency Response : 50-250 Hz
  • Number of Channels : 5
  • Frequency Response : 20-20000 Hz
  • RMS Power Output : 500 Watts
  • RMS Power Range : 4x125+300 Watts
  • Amplifier Class : A/B+BD
  • Fuse Rating : 150 A

FEATURES


Features:

  • High level input capable with Auto Turn-On circuit
  • 12dB/octave Butterworth crossover
  • Features C.L.E.A.N. Set-up
  • On-board Punch EQ with +18dB boost @ 45Hz
  • Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator)
  • Muted turn on
  • Stealth top mounted control panel
  • Short circuit protection
  • Cast aluminum heatsink
  • Over current protection
  • Infrasonic filter
  • 2/4 channel input switch
  • Marine grade two part epoxy coating on circuit boards
  • Marine grade stainless steel hardware
  • 2-Year Warranty



Specifications:

  • Cta-2006 Compliant
  • Number of Channels: 5
  • Total Power (Sum of Rated Power): 1000 Watts
  • Rated Power (RMS Continuous Power)
    • 75 Watts x 4 + 150 Watts x 1 @ 4-Ohm
    • 125 Watts x 4 + 300 Watts x 1 @ 2-Ohm
    • 500 Watts @ 1-Ohm
  • Dynamic Power (PVC/PowerCube®)
    • 115 Watts x 4 + 299 Watts x 1 @ 4-Ohms 0° Res
    • 190 Watts x 4 + 540 Watts x 1 @ 2-Ohms 0° Res
    • 863 Watts x 1 @ 1-Ohm 0° Res
  • Bridgeable: Yes (front/rear channels)
  • Frequency Response
    • Front/Rear: 20Hz - 20kHz +/-3dB
    • Sub: 20Hz - 500Hz +/-3dB
  • Input Sensitivity: 150 mV - 12 V
  • Circuit Topology Class: Class A/B + Class BD (Sub)
  • Efficiency (average)
    • Front/Rear: 66% @ 4-Ohm
    • Sub Channel: 80% @ 4-Ohm
  • Total Harmonic Distortion (THD+Noise): <1.0%
  • Signal Input
    • Input Switch: Hi/Low level input
    • Input Switch: 2/4 channel input
    • Hi/Low Level: 3 RCA Pair
    • Sub: front/sub input switch
  • Tone Controls: Sub: 0dB to +18dB @ 45Hz
  • Crossover Controls
    • Front: 50Hz - 250Hz High-Pass @ 12dB/Octave
    • Rear: 50Hz - 250Hz High-Pass @ 12dB/Octave
    • Sub: 50Hz - 250Hz Low-Pass
    • Sub: 28Hz infrasonic filter @ 12dB/Octave
  • Remote Controls: Optional Punch Level Control (PLC2) Ready
  • Visual Indicators
    • Power/Protect/Thermal LED
    • Input Clip LED3
    • Output Clip LED1,2,3
    • LED Color Legend:
    • 1BLUE: <0.5% THD
    • 2VIOLET: 1% THD
    • 3RED: 10%+ THD
  • Power Wire Gauge: 4 AWG
  • Power Input Connector: Block
  • Speaker Wire Gauge: 12 AWG
  • Speaker Output Connector: Block
  • Cooling: Convection
  • Operating Voltage: 9 - 16 VDC
  • Recommended Fuse (not included): 150 A
  • Average Current Draw (13.8V Music): 75 A
  • Max. Current Draw (13.8V Sinewave): 150 A
  • Suggested Alternator: 100 A
  • Dimensions (H x W x D): 2.38 x 7.76 x 15.03 (in)
    • 6.05 x 19.71 x 38.18 (cm)
  • Shipping Weight: 15.3 Lbs. (6.93 Kg.)
  • UPC: 780687345211
  • Weight: 16
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
