Orion DB1248 Cobalt One 2/4 Gauge In and Four 8 Gauge Out Nickle
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
Versatile Power Distribution with Reliable Performance
The DB1248 Power Distribution Block offers flexible power management with one 2/4 gauge input and four 8 gauge outputs, ideal for multi-amplifier car audio systems. Engineered for reliable performance, it ensures safe and efficient power transfer, providing stable operation and protection for all your audio components.
Durable, Professional, and Stylish
Constructed from high-quality materials with a corrosion-resistant nickel finish, the DB1248 Power Distribution Block ensures long-lasting reliability while its sleek nickel coating adds a polished, professional look to any car audio installation.
Organized, Stylish, and Functional
The DB1248 Power Distribution Block helps create an organized setup, keeping your system clean and simplifying power management in complex audio configurations. Ideal for enthusiasts, it combines style and functionality for high-performance car audio systems.
Frequently Asked Questions (FAQ)
- • Why Do the DB1248 Set Screws Keep Coming Loose?
One user specifically reported that the set screws did not stay tight because the threaded housing was too thin. If a connection loosens, inspect the terminals and cable retention before operating a high-current system.
- • Why Are the Four DB1248 Output Terminals So Close Together?
A customer review complained that the output connections were positioned too closely together, which can make larger 8-gauge cables more difficult to route and tighten. Plan the cable direction before mounting the block.
- • Why Did the Plastic Cover on My Orion DB1248 Crack?
One purchaser reported that the protective plastic cover broke easily. When installing or servicing the block, avoid excessive pressure on the cover and make sure the cables are not forcing against it.
- • Can the Orion DB1248 Split One Main Power Cable Between Four Amplifiers?
Yes, its design provides one 2/4-gauge input and four 8-gauge outputs, making it suitable for distributing one main power feed to multiple amplifier circuits when the overall wiring and protection are properly sized.
- • Why Does My Amplifier Lose Power After Connecting It to the DB1248?
If an amplifier loses power after installation, check the specific output terminal, cable crimp, fuse, and connection at the amplifier. A poor connection at the distribution block can interrupt the power path even when the main input still has voltage.
- • Can I Use All Four DB1248 Outputs at the Same Time?
The four outputs are intended to distribute power to multiple circuits, but the total current demand must remain appropriate for the main cable and upstream protection. The four output ports should not be interpreted as four independent high-current sources.
- • Why Does My DB1248 Connection Get Hot Under Heavy Load?
Heat around a power-distribution connection can indicate high current, excessive resistance, an undersized cable, or a loose terminal. Users should inspect the connection rather than continuing to operate the system if the terminal becomes unusually hot.
- • Why Won't My Large Power Cable Fit Securely Into the DB1248?
The DB1248 accepts a 2/4-gauge input, while its four outputs are designed for 8-gauge cables. Trying to force an incorrectly sized cable into a terminal can result in a poor electrical connection.
- • Why Does My DB1248 Installation Look Crowded After Adding Multiple Amplifiers?
Four outgoing 8-gauge cables can make the installation difficult to organize, particularly when amplifiers are mounted in different directions. One user specifically criticized the close spacing of the outputs, so allowing enough clearance around the block can make installation easier.
- • Can Loose DB1248 Terminals Cause Intermittent Amplifier Problems?
Yes. An inconsistent connection at a distribution block can interrupt power or introduce resistance, potentially causing an amplifier to behave intermittently. One user specifically reported concerns with the DB1248's set screws staying secure, making terminal inspection especially important.
- Gauge In : 2/4 AWG
- Gauge Out : 8 AWG
- Number of Inputs : 1
- Number of Outputs : 4
Features:
- Versatile Power Distribution: The DB1248 Power Distribution Block features one 2/4 gauge input and four 8 gauge outputs, making it perfect for multi-amplifier car audio systems.
- Reliable Performance: Engineered for safe and efficient power transfer, ensuring stable operation and protection for your audio components.
- Durable Construction: Crafted from high-quality materials with a corrosion-resistant nickel finish for long-lasting reliability.
- Professional Aesthetic: The sleek nickel coating adds a polished, professional look to your installation.
- Organized Setup: Helps maintain a clean and efficient layout, simplifying power management in complex audio systems.
- Ideal for Enthusiasts: Perfect for audiophiles seeking both style and functionality in their high-performance car audio setups.
Specifications:
- Model: DB1248
- Type: Power Distribution Block
- Input: 1 x 2/4 Gauge
- Outputs: 4 x 8 Gauge
- Dimensions (L x W x H): 2.95" x 0.91" x 0.98" (74.93 x 23.11 x 24.89mm)
- Material: Nickel-Plated Metal
- Color: Nickel
- Mounting Style: Inline / Panel Mount
- Use: Car Audio Power Distribution and Circuit Protection
- Features: Corrosion-Resistant, Durable Design, Organized Installation
- UPC: 818550011755
- Weight: 1
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
