4-Way Fused Power Distribution Block Designed to split a large wire down to four smaller wires where fusing of the small wires is needed. The input of this block accepts wire from 1/0 to 4 AWG, while the four fused outputs each accept wire from 4 AWG to 8 AWG. OmniSert™ receptacles capture various size wires without the need for adaptor sleeves. Forged and machined brass construction with marine-grade stannum plating.
A high-temperature polycarbonate base and cover provide insulation and protection. Requires four MAXI® Fuses, appropriately rated for the equipment being connected. These are sold separately. Fuses can be pulled and inserted without removing the cover.
General Features:
- One 1/0 - 4 AWG Input
- Four 4 - 8 AWG Outputs
- Fuses can be pulled and inserted without removing the cover
- OmniSert™ receptacles capture various size wires without the need for adaptor sleeves
- Forged and machined brass construction
- Marine-grade stannum plating
- High-temperature polycarbonate base
- Requires four MAXI Fuses, sold separately
- Gauge In: 1/0-4 AWG
- Gauge Out: 4-8 AWG
- Number of Inputs: 1
- Number of Outputs: 4
- Fuse Holder: YES
Product Highlights:
- One 1/0 - 4 AWG Input
- Four 4 - 8 AWG Outputs
- Fuses can be pulled and inserted without removing the cover
- OmniSert™ receptacles capture various size wires without the need for adaptor sleeves
- Forged and machined brass construction
- Marine-grade stannum plating
- High-temperature polycarbonate base
- Requires four MAXI Fuses, sold separately
- UPC: 699440904629
- Weight: 2
- Sku: 90462
- Authorized Internet Dealer
*Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
