What's Included:
- Limited Warranty Information (US/CA)
- Wiring harness
- Owner's Manual (En/Fr/Sp)
- 6 Pan head ISO-mount screws (M5 x 8mm)
- Digital media receiver (10A fuse)
- Two-sided tape
- Wireless remote control (CXE9605)
- CR2025 Lithium battery (installed)
- Microphone w/ sunvisor clip (attached 13' cable terminated by a right-angle male 2.5mm connector)
- 6 Flat-head ISO-mount screws (M5 x 9mm)
Product Highlights:
- Remote control
- Fits double-DIN (4"-tall) dash openings
- 13-band graphic equalizer
- 1.5 amp USB charges your phone while you're playing music
- Low-pass/high-pass filters
- Inputs: front USB port and front AUX input
- Works with SiriusXM satellite radio tuner
- Convenient Siri Eyes Free functionality
- MIXTRAX virtual DJ technology
- Advanced Sound Retriever (ASR) restores sound to compressed files
- Digital media receiver with AM/FM tuner (does not play CDs)
- Built-in MOSFET amplifier (14 watts RMS CEA-2006/50 peak x 4 channels)
- Built-in Bluetooth for hands-free calls and music streaming
- Plays MP3, WMA, AAC, FLAC, and WAV music files
- Variable color illumination
- External microphone included
- Built-in iPod, iPhone, and iPad control
- AOA 2.0 for music streaming and control from Android
- Bluetooth features include Dual Phone Pairing and Guest Mode
- Works with Spotify and Pandora for iPhone and Android
- Outputs: 6-channel preamp outputs
- Maximum Power : 50 Watts
- Satellite Radio Ready : Yes
- Remote Control : Yes
- RMS Power Output : 14 Watts
- Subwoofer Preamp Outputs : Yes
- Built-in EQ : Yes
- Preamp Voltage : 2 volts
- Bluetooth : Yes
- Aux Input : Yes
- MP3 Playback : Yes
- WMA Playback : Yes
- HD Radio : No
- Preamp Outputs : Yes
For a high quality audio and music experience in your vehicle, Pioneer audio receivers provide customizable sound settings and adjustments that help you create the best sound environment in your vehicle, tailored to your musical preferences.
Also, multiple audio codec playback ability contributes to produce superb sound. With the 13-Band Graphic Equalizer, adjust acoustic settings in highly personalized detail from either the receiver or the Pioneer ARC App. 3-Way Network Mode allows you to connect up to three external amplifiers (via three preouts), dedicated to driving high-, mid- and low-frequency ranges, respectively. The result: more distinct separation of the three frequency range, for more full, natural sound, realizing more of each speaker’s potential in a multispeaker system.
Access music on your smartphone directly from the Pioneer receiver. Search for Artist, Albums and Songs using Pioneer's intuitive interface. With Pioneer receivers you can also access and control select music and radio apps on your smartphone. Pioneer's ARC (Advanced Remote Control) app allows you to use your smartphone to control select functions on your Pioneer receiver. Access functions including presets, fast forward and rewind, and artist and album search.
Built-in Bluetooth® Pioneer Audio receivers feature built-in Bluetooth® that enables both hands-free calling and audio streaming. Including the latest Hands-Free Profile (HFP 1.6) with Wideband Speech capability.
You are able to experience more natural sound quality and details during calls. When streaming music, AVRCP 1.5 lets you browse and select the media stored on your smartphone.
See more details below.
Specifications |
Wireless Remote |
Yes |
Nano |
7/6/5/4/3/2/1 |
No |
Siri Control |
Steering Wheel Control Compatible |
Adapter required |
Touch |
6/5/4/3/2/1 |
Peak Output |
50 watts |
USB memory |
Bluetooth Compatible |
iPhone |
7+/7/6S+/6S/6+/6/5S/5C5/4S/4/3 |
AUX Input Front |
Audio/video Input |
EQ Bands |
13 |
Radio Data System |
Yes |
Preamp Outputs |
6-channel |
Front |
CarPlay |
Seek/Scan |
Seek |
N/A |
USB Input |
RMS Power Bandwidth |
20-20kHz |
Built-in |
Satellite Radio Ready |
Video Screen |
No |
Display Color |
Variable |
CEA-2006 Compliant |
Yes |
No |
Android Auto |
Yes |
Android Control |
Yes |
Memory Card Slot |
SiriusXM |
3.0 |
HD Radio |
No |
Navigation |
N/A |
Full size |
Classic/5Gen |
RMS Power Output |
14 watts |
Sub Preamp Outputs |
Yes |
Switchable Rear Preamp Outputs |
No |
Preamp Voltage |
2 volts |
Key Button Color |
Variable |
FM Sensitivity |
11 dBf |
European Tuning |
No |
