Kenwood Excelon XR-W1204 Excelon Series Oversized Component Subwoofer
We are a Kenwood Excelon authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
- •One 12" Subwoofer
- •Eight 1-3/8" Screws
- •Adhesive backed foam gasket
- •Cardboard template
- •Warranty information
- •Specs on box lid
- •Owner's Manual
Ready to Rock
Kenwood puts their most advanced technology into the Excelon subwoofers, so you can enjoy reliable high-performance bass in your ride. The oversized XR-W1204 12" sub is designed to move more air than a standard sub, which means more sound in your vehicle. It comes equipped with an oversized polypropylene cone attached to a heavy-duty rubber surround that allows for extra excursion, so it'll faithfully reproduce those low notes. The XR-W1204 is rated to handle up to 400 watts RMS so you know it's ready to rock.
Cooler During Extended Play
A dual ventilation system forces heated air out of the motor structure through the back and the sides of the housing, so the sub stays cooler during extended play. This ventilation system also allows this sub to operate in a shallow enclosure, good news if you're building a box to go in a tight spot. Install this Kenwood in a suitable box, hook up a nice amp, and you're ready to rumble.
- Diameter : 12 Inch
- Sensitivity : 83 dB
- Impedance : 4 Ohm
- Frequency Response : 32-300 Hz
- Peak Power Handling : 2000 Watts
- Top Mount Depth : 5-5/8 Inches
- Number of Voice Coils : Single
- Suggested Sealed Box Volume : 0.88 Cubic ft.
- Suggested Ported Box Volume : 1.5 Cubic ft.
- RMS Power Handling : 400 Watts
- 12" 4-Ohm Subwoofer
- Peak: 2000 watts
- RMS: 400 watts
- Recommended power range: 200 - 400 RMS
- PP Cone
- Rubber Surround
- Stress-free Spider
- Steel Basket
- 8AWG Push Terminal
- Ferrite Magnet
- Top-mount depth: 5 5/8"
- Cutout diameter: 11"
- Frequency Response: 32- 300Hz
- Sensitivity: 83dB
- UPC: 019048215888
- Weight: 13
