6 inputs and 6 outputs including front – rear and subwoofer
Selectable high and low level inputs
Front – rear and subwoofer outputs have an independent two-way crossover in-line with the EQ
Front and rear outputs can be delayed independently up to 10ms
Easy behind the radio installation
Can be used with OE and aftermarket radios
Chime control for vehicles with amp-generated chimes (When retaining OEM radio)
Retains Sonar sensors in vehicles where the tone is provided by the amplifier (When retaining OEM radio)
Clipping detection and limiting circuits
Retains OE voice prompts (SYNC and OnStar)
Settings adjusted via Bluetooth application compatible with both Android and Apple devices
Read – Write and Store your configuration for future recall.
Input Channels: 6 High/Low level Selectable
Input Options: High Level or Low Level
Input Type: Differential-Balanced
Input Voltage High Level Range: 0 - 15.5 volts Peak to Peak
Input Voltage Low Level Range: 0 - 4.9 volts Peak to Peak
Output Channels: 6 Outputs
Analog Output: Unbalanced RCA Jacks
Output Voltage: 5V RMS
Output Impedance: 47 Ohms
Equilizer Type: 31 Band Graphic EQ, +/- 10dB
Frequency Responsw: 20-20kHz
Crossover: 2-Way LPF / HPF per channel
Crossover Type: Linkwitz-Riley 4BdB Slope, Fixed
S/N Ratio: 92dB @ 5V RMS
Operating Voltage: 10 - 16VDC
Standby Current Draw: ~7mA
Operating Current Draw: ~150mA
Adjustments/Controls: Application via Bluetooth
Remote Output: 12 volt DC, Signal Sense or with Ignition
Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
