Audison  TH Quattro

THESIS Series 4-Channel 340W RMS x 4 at 1-Ohm, Class-A Car Amplifier

Item #54245

Condition:   Brand New

0
❮ ❯
TH Quattro

Additional product image
Additional product image
Additional product image
Additional product image
Product Highlights
  • Thesis 4-Channel Amplifier
  • 340W RMS x4 Power
  • Class A Car Amplifier
  • 1-Ohm Stable High Power
  • Premium Car Audio System
  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
CYBER WEEK DEALS!
Save 5% on 4 Channel Amplifiers!

Use Code: CYBW5

Ends in:

0 Review

$5,999.99

Reg. Price $6,600.00  Save $600.01
Available to Order
Add Extended Warranty
  Free 2-Years Warranty Included!
Add to Cart
 Alert me on price change

No Credit needed for acima logo. Learn More

 Fit Guide. Check if it will fit your car.
We Price Match! Call Us! 310-526-8635
Audison Authorized Dealer

Huge Saving on Other items:

Huge Saving on Other items:

Audison Banner

Audison TH Quattro - THESIS Series 4-Channel 340W RMS x 4 at 1-Ohm, Class-A Car Amplifier

We are a Audison authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • 4-Channel Car Amplifier
  • • Printed Quick Start Guide
  • • 1.0 m AC Link (RJ-12)cable
  • • 1.0 m AD Link (RJ-45)cable
  • • 2.0 m USB cable
  • • USB/AC Link converter
  • • N. 2 TH-MXR stereo module
  • • N.16 frequency set modules (SS1-SW1-SW2-WM1-WM2-MT1-WT1-MT2)
  • • N. 4 CFB customisation modules
  • • N. 4 Fixing screws and plastic bushing
  • • Multi spanner tooling
  • • INSTALLATION CD with: CD ROMACNet Software
  • • USB-ACNet Drivers
  • • TEST SIGNALS
  • • Owner's Manual





Musway CSM206x Speaker Image
Elevating Car Audio with Analog-Digital Fusion

Thesis amplifiers leverage the expertise and knowledge gained from the HV venti, enhanced by the integration of digital technology innovation. This fusion results in a flawless amalgamation of top-tier analog technology and advanced digital features within a singular product. The invaluable collaboration with Full DA HD technology elevates the in-car listening experience to unprecedented levels of excellence, representing the culmination of distinctive expertise applied to mobile audio reproduction. The TH quattro, a four-channel amplifier, offers full adjustability and complete manageability through its internal microprocessor, allowing for limitless system configurations.

SPECIFICATIONS

  • Maximum Power : 1400 Watts
  • Number of Channels : 4
  • Frequency Response : 5-70000 Hz
  • Amplifier Class : A
  • Fuse Rating : 100 A

FEATURES

Features:

  • Utilizes complementary differential circuitry with a current mirror.
  • Features a Cascode A Class driver with inverted complementary triplet power stages.
  • Incorporates integrated 24-bit / 192 kHz Hi-End DA converters.
  • Compatible with Audison Full DA HD technology and certified for Hi-Res audio file playback.
  • Equipped with SPDIF and AD Link optical digital inputs capable of managing up to 8 digital channels via an RJ-45 connector.
  • Dual Mono Construction with four power supplies in Synchro-PWM configuration.
  • Sensitivity control with 256 steps resistive switching, offering a resolution of 120 dB.
  • Offers Energy Saving, Hi-Current, Hi-AB Class, and A Class presets that can be selected in real-time.
  • Provides digital control through an integrated settings panel, DRC, and PC software.
  • Includes a high-quality crossover module.
  • The chassis is extruded from solid aluminum and constructed using CNC machines.



Specifications:

Power Supply:

  • Voltage: 11 ÷ 15 VDC
  • Idling current (@ Dual Power Setting): 2.6 ÷ 8.9 A
  • Idling current when off: 0.04 mA
  • Consumption @ 14.4 VDC, 1 Ω,
  • Max Musical Power: 105 A
  • Remote In: 7 ÷ 15 VDC (1 mA)
  • Remote Out : 12 VDC (20 mA)
  • Fuse (AFS): 100 A



Amplifier Stage:

  • Distortion - THD @ 1 kHz, 4 ohms: 90% Power: 0.03 %
  • Bandwidth @ -3 dB, 2 VRMS, 4 ohms: 5 ÷ 70k Hz
  • S/N ratio @ A weighted, 1 V, Max Power: 104 dBA
  • Damping factor @ 1 kHz, 2 VRMS, 4 ohm: 80
  • Pre-In sensitivity (two ranges): 0.3 ÷ 4.8 VRMS
  • Pre-In impedance: 15k ohmsTH Quattro



Power Output:

  • (RMS) @ 14.4
  • VDC, 1% THD: Dual Power Mode - Hi Current:
  • 4 Ch @ 4 Ω: 160 W x 4
  • 4 Ch @ 2 Ω: 260 W x 4
  • 4 Ch @ 1 Ω: 340 W x 4
  • 3 Ch @ 4 Ω: 150 W x 2 + 540 w x 1
  • 3 Ch @ 2 Ω: 250 w x 2 + 650 w x 1
  • 2 Ch @ 4 Ω: 500 W x 2
  • 2 Ch @ 2 Ω: 700 W x 2
  • Dual Power Mode - A Class: 4 Ch @ 4 Ω 55 W x 4



  • UPC: 8018823088442
  • Weight: 10
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
