• CD receiver (10A fuse)
• Face (attached)
• Trim ring (attached)
• Sleeve (installed)
• Wiring harness
• Microphone w/ bracket (attached 10' cable terminated by a right-angle mono 3.5mm connector)
• 2 Removal tools
• Face-fixing screw
• Owner's Manual
Enjoy convenient control of popular apps like Spotify and Pandora, built-in Bluetooth for hands-free calls and streaming music, as well as the ability to use your smartphone like a wireless remote control.
The Best Audio Experience
Sound quality enthusiasts will love the playback support of various types of music formats, including compatibility with FLAC files. Simple sound customization is also available with its built-in 13-Band EQ and Digital Time Alignment.
Satellite Radio Ready : No
Built-in EQ : Yes
DIN : 1
Preamp Voltage : 2.5 volts
Bluetooth : Yes
Aux Input : Yes
MP3 Playback : Yes
WMA Playback : Yes
HD Radio : No
Front USB Input : 1
Preamp Outputs : 2
RDS - Radio Data System : Yes
Apple CarPlay : No
Android Auto : No
Frequency Range (Frequency step): 87.9MHz to 107.9MHz(200kHz)
Channel Space Selection
Usable Sensitivity(S/N 30dB): 8.2dBf (0.71μV/75Ω)
Quieting Sensitivity (DIN S/N:46dB): 17.2dBf (2.0μV/75Ω)
Frequency Response (±3.0dB): 30Hz to 15kHz
Stereo Separation: 40dB(1kHz)
Frequency Range (Frequency Step): 530kHz to 1700kHz (10kHz)
Channel Space Selection
Usable Sensitivity S/N: 20dB: 29dBμ (28.2μV)
Laser Diode: GaAlAs
Digital Filter(D/A): 8 Times OverSampling
Spindle Speed: 500 to 200rpm (CLV)
Wow & Flutter: Below Measurable Limit
Frequency Response: 20Hz to 20kHz(±1dB)
Total Harmonic Distortion: 0.02%(1kHz)
S/N Ratio (dB): 99dB(1kHz)
Dynamic Range: 92dB
Channel Separation: 90dB
MP3 Decode: Compliant with MPEG-1/2 Audio Layer-3
WMA Decode: Compliant with WINDOWS MEDIA AUDIO
AAC Decode: AAC-LC ".aac" files
WAV Decode: -
4 to 8 ohms
USB: USB 1.1 / 2.0 High Speed
File System: FAT12 / 16 / 32
Maximum Supply current: DC5V(DC logo) 1.5A
MP3 Decode: Compliant with MPEG-1/2 Audio Layer-3
WMA Decode: Compliant with Windows Media Audio
AAC Decode: AAC-LC ".aac",".m4a" files
WAV Decode: Linear-PCM
FLAC Decode: FLAC file (Up to 24bit/96kHz)
Frequency Response: 20Hz to 20kHz ±3dB
Input Maximum Voltage: 1000mV
Input Impedance: 30k ohms
Maximum Power: 50Wx4
Full Bandwidth Power (at less than 1%THD): 22Wx4
Band1: 62.5Hz ±9dB
Band2: 100Hz ±9dB
Band3: 160Hz ±9dB
Band4: 250Hz ±9dB
Band5: 400Hz ±9dB
Band6: 630Hz ±9dB
Band7: 1kHz ±9dB
Band8: 1.6kHz ±9dB
Band9: 2.5kHz ±9dB
Band10: 4kHz ±9dB
Band11: 6.3kHz ±9dB
Band12: 10kHz ±9dB
Band13: 16kHz ±9dB
Version: Bluetooth 4.2
Frequency Range: 2.402 to 2.480GHz
RF Output Power (E.I.R.P.): +4dBm (MAX), Power Class 2
Maximum Communication range: Line of sight approx.10m(32.8ft)
HFP 1.7.1 (Hands Free Profile)
SPP (Serial Port Profile)
PBAP (Phonebook Access Profile)
A2DP (Advanced Audio Distribution Profile)
AVRCP 1.6.1 (Audio/Video Remote Control Profile)
Operating voltage: 12V DC car battery
(W) 182(mm) 7-3/16(in)
(H) 53(mm) 2-1/16(in)
(D) 155.5(mm) 6-1/8(in)
Net Weight (trim plate and mounting sleeve included): 1.2(kg) 2.7 (lbs)
