MB Quart  FA1-2000.1

Formula Series 500 x 1 @4Ohms (2000 Max Power) Mono Subwoofer Car Audio Amplifier

Item #56491

Condition:   Brand New

0
❮ ❯
Product Highlights
  • Formula Series
  • 500W x 1 @ 4 Ohms
  • 2000W Max Power
  • Mono Subwoofer
  • Car Audio Amplifier
  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
0 Review

$135.30

Reg. Price $349.99  Save $214.69
Add to Cart
Out of Stock Check out other products listed below
Or call us at 310-526-8635 and our expert tech-support would be happy to suggest alternative products for you!
Or email at [email protected]
 Fit Guide. Check if it will fit your car.
MB Quart Authorized Dealer

Huge Saving on Other items:

Available alternative products:

Huge Saving on Other items:

MB Quart Banner

MB Quart FA1-2000.1 2000 Watt Amplifier 1 Ohm Stable Mono Car Audio Amp

We are a MB Quart authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • •Mono Car Audio Amp
  • • Owner's Manual
Sensing to Allow Any Amplifier to Be Easy Integrated

MB Quart Formula series mono subwoofer car audio amplifier featuring innovative sound quality and power technology. The FA1-2000.1 is a 2000 watt 1 ohm stable car audio amplifier. Formula amplifiers feature DC Sensing to allow any amplifier to be easy integrated into an OEM system by simply adapting a RCA cable from the source unit. Bass remote is included.

On-board Electronic Crossover

Control of amplifier output with on-board electronic crossover to tailor specific frequencies to speakers and subwoofers. Check specifications for specific frequencies for this amplifier. Class Q1 Mono (Class D): MB Quart’s Class Q1 offers the efficiency of today’s D-Class with increased engineering to focus on sound quality from the power supply through the output devices, the FLUID-FETS.

Painstakingly Selected for Their Ability

FLUID-FETS: MB Quart output devices, FLUID-FETS are painstakingly selected for their ability to efficiently produce power and mimic the sound quality of the highest end home amplifiers.Rugged MOSFET Pulse Width Modulation power supply: Allows amplifier to product efficient power without taxing the vehicle electrical system.

  • Maximum Power : 4000 Watts
  • Low Frequency Response : 50-250 Hz
  • Number of Channels : 1
  • Frequency Response : 15-250 Hz
  • Built In Crossovers : Yes
  • RMS Power Output : 1000x1 Watts
  • Amplifier Class : D
  • Fuse Rating : 25x4 A

Features:

  • Low Noise Preamplifier Circuitry - Q-stasis Pre Amplifier Stage: Maximum Low Voltage Signal From The Source Unit Comes Into The Amplifier Circuit With Minimal Distortion
  • Rca InputsNickel Plated -  High Temperature Impact Resistant With Hex Screw Terminals That Allow For Secure Connections And Is Erosion Resistant
  • Hi Level Inputs -  Dc Signal Sense: The Dc Signal Sense Switch Will Allow The Amp To Turn On When A Signal Is Received On The Rca Inputs, So An Amplifier Remote Turn On Wire Is Not Needed To Turn On The Amplifier. This Feature Can Also Be Turned Off.
  • Operation Mode - Mono Only
  • Variable Electronic Crossovers -  Allow For Complete Control Of The Sound Electronic Equalizer Control Of Amplifier Output With On-board Electronic Crossover To Tailor Specific Frequencies To Speakers And Subwoofers. Check Specifications For Specific Frequencies For This Amplifier.
  • Class / TopologyClass Q1 Mono (Class D) - Mb Quart’s Class Q1 Offers The Efficiency Of Today’s D-class With Increased Engineering To Focus On Sound Quality From The Power Supply Through The Output Devices, The Fluid-fets.
  • Output Device TechnologyFluid-fets -  Mb Quart Output Devices, Fluid-fets Are Painstakingly Selected For Their Ability To Efficiently Produce Power And Mimic The Sound Quality Of The Highest End Home Amplifiers.
  • Heat Sink - Heavy Duty Heat-sink Efficiently Moves Heat From The Mosfet Where It Can Be Cooled
  • Power Supply - Rugged Mosfet Pulse Width Modulation Power Supply: Allows Amplifier To Product Efficient Power Without Taxing The Vehicle Electrical System
  • Output Connections - Heavy Duty Connections Allow For Secure Electrical Signal To Pass Into Wiring And Resist Erosion Which Will Add Longevity To The Amplifier
  • Connection Type - Secure Connection For All Power, Ground And Speaker Connections.
  • Led System Protection Circuitry Diagnostics - Monitor Overload And Speaker Short Protection With Illuminated Indicators On The Amplifier End Panel
  • Bass Remote Included - Included On Mono And 5 Channel Amplifiers. This Allows The Driver To Make Subtle Changes To The Bass Respond Of The Audio System From The Seated Listening Position.



Specifications:

  • Class: Class Q1 Mono (Class D)
  • Total Channels: Mono
  • Power @ 1 Ohm: 1 X 2000 Watts
  • Power @ 2 Ohms: 1 X 1000 Watts
  • Power @ 4 Ohms: 1 X 500 Watts
  • Crossover: Electronic
  • Variable Low Pass Crossover 12db Per Octave: Variable, 50hz - 250hz
  • Bass Boost: 0-12db
  • Subsonic Filter: 10hz - 40hz
  • Variable Voltage: .02 - 9v
  • Signal To Noise: >90
  • Frequency Response: 15hz-250hz
  • Total Harmonic Distortion (Thd): <0.10%
  • Speaker Level Audio Inputs: Rca Jack
  • Power Terminal 12v/gnd: 4 Awg
  • Speaker Terminal Wire Gauge: 12 Awg
  • Fusing: 25a X 4
  • UPC: 806576230168
  • Weight: 10
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.

Do you own this product?

Write a review!
  • Maximum Power : 4000 Watts
  • Low Frequency Response : 50-250 Hz
  • Number of Channels : 1
  • Frequency Response : 15-250 Hz
  • Built In Crossovers : Yes
  • RMS Power Output : 1000x1 Watts
  • Amplifier Class : D
  • Fuse Rating : 25x4 A

Features:

  • Low Noise Preamplifier Circuitry - Q-stasis Pre Amplifier Stage: Maximum Low Voltage Signal From The Source Unit Comes Into The Amplifier Circuit With Minimal Distortion
  • Rca InputsNickel Plated -  High Temperature Impact Resistant With Hex Screw Terminals That Allow For Secure Connections And Is Erosion Resistant
  • Hi Level Inputs -  Dc Signal Sense: The Dc Signal Sense Switch Will Allow The Amp To Turn On When A Signal Is Received On The Rca Inputs, So An Amplifier Remote Turn On Wire Is Not Needed To Turn On The Amplifier. This Feature Can Also Be Turned Off.
  • Operation Mode - Mono Only
  • Variable Electronic Crossovers -  Allow For Complete Control Of The Sound Electronic Equalizer Control Of Amplifier Output With On-board Electronic Crossover To Tailor Specific Frequencies To Speakers And Subwoofers. Check Specifications For Specific Frequencies For This Amplifier.
  • Class / TopologyClass Q1 Mono (Class D) - Mb Quart’s Class Q1 Offers The Efficiency Of Today’s D-class With Increased Engineering To Focus On Sound Quality From The Power Supply Through The Output Devices, The Fluid-fets.
  • Output Device TechnologyFluid-fets -  Mb Quart Output Devices, Fluid-fets Are Painstakingly Selected For Their Ability To Efficiently Produce Power And Mimic The Sound Quality Of The Highest End Home Amplifiers.
  • Heat Sink - Heavy Duty Heat-sink Efficiently Moves Heat From The Mosfet Where It Can Be Cooled
  • Power Supply - Rugged Mosfet Pulse Width Modulation Power Supply: Allows Amplifier To Product Efficient Power Without Taxing The Vehicle Electrical System
  • Output Connections - Heavy Duty Connections Allow For Secure Electrical Signal To Pass Into Wiring And Resist Erosion Which Will Add Longevity To The Amplifier
  • Connection Type - Secure Connection For All Power, Ground And Speaker Connections.
  • Led System Protection Circuitry Diagnostics - Monitor Overload And Speaker Short Protection With Illuminated Indicators On The Amplifier End Panel
  • Bass Remote Included - Included On Mono And 5 Channel Amplifiers. This Allows The Driver To Make Subtle Changes To The Bass Respond Of The Audio System From The Seated Listening Position.



Specifications:

  • Class: Class Q1 Mono (Class D)
  • Total Channels: Mono
  • Power @ 1 Ohm: 1 X 2000 Watts
  • Power @ 2 Ohms: 1 X 1000 Watts
  • Power @ 4 Ohms: 1 X 500 Watts
  • Crossover: Electronic
  • Variable Low Pass Crossover 12db Per Octave: Variable, 50hz - 250hz
  • Bass Boost: 0-12db
  • Subsonic Filter: 10hz - 40hz
  • Variable Voltage: .02 - 9v
  • Signal To Noise: >90
  • Frequency Response: 15hz-250hz
  • Total Harmonic Distortion (Thd): <0.10%
  • Speaker Level Audio Inputs: Rca Jack
  • Power Terminal 12v/gnd: 4 Awg
  • Speaker Terminal Wire Gauge: 12 Awg
  • Fusing: 25a X 4
  • UPC: 806576230168
  • Weight: 10
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
