Description
The IntelliCHARGER generates a low DC voltage and high DC current to the battery being charged. Operating the IntelliCHARGER incorrectly or misusing it may damage the charger or create hazardous conditions for the user
General Features:
- TYPE: 12/14/16V Battery IntelliCharger, 5A, 15A, 25A
- AC Input Connections: 5.0’ (1.5 m) AWG 16
- DC Output Connections: 6.0’ (1.8 m) AWG 10
- Dimensions (W x H x D) : 8 5/8” W x 7” H x 11 1/8” D
General Safety Precautions
The IntelliCHARGER is designed to charge 12V, 14V and 16V lead-acid batteries of all types. Do not attempt to use with batteries of other voltages.
Do not use this product where there are flammable fumes or gases.
Do not use this product in an enclosure containing lead-acid batteries. These batteries vent explosive hydrogen gas, which can be ignited by sparks from electrical connections.
Never attempt to charge a frozen battery.
Features:
- Compatibility: Charges 12V, 14V, and 16V lead-acid batteries (AGM, gel-cell, deep cycle, maintenance-free).
- Multi-Stage Charging:
- Bulk Charge: Restores 80% of capacity rapidly.
- Absorption Charge: Completes charging and equalizes cells.
- Float Charge: Maintains full charge indefinitely.
- Adjustable Charging Rates: Selectable 5A, 15A, or 25A charging levels.
- LED Indicators: Display modes for voltage, amperage, charging, float, and error statuses.
- Digital Output Display: Monitors volts and amps during operation.
- Voltage Selection: Supports 12V, 14V, or 16V battery setups with front panel switches.
- Automatic Shutdown: Ensures safety by shutting down if the battery cannot reach required levels or is incorrectly connected.
- Internal Cooling System: Built-in fan prevents overheating during operation.
- Durable Battery Cables: Heavy-duty 6 ft. cables with soldered connections for maximum current flow.
- Error Detection: Built-in microprocessors identify and display error codes for troubleshooting.
- Safety Features: UL-approved cables and components with protective mechanisms against overload and overheating.
Specifications:
- Voltage Type: 12V, 14V, and 16V.
- Charging Rates: 5A, 15A, 25A.
- Dimensions: 8 5/8” W x 7” H x 11 1/8” D.
- Weight: 24 lbs (10.87 kg).
- AC Input: 120VAC or 230VAC, 50/60Hz, 10A RMS.
- Output Voltage:
- 12V: 14.40V (absorption), 13.56V (float).
- 14V: 16.80V (absorption), 15.82V (float).
- 16V: 19.20V (absorption), 18.08V (float).
- Safety Protections: Includes fuse protection, error indicators, and automatic recovery mechanisms.
- Cable Specifications: 5 ft. AC input cord (16 AWG); 6 ft. DC output cord (10 AWG).
Physical Specifications:
- Dimensions: 8 5/8” W x 7” H x 11 1/8” D
- Weight: 24 lbs (10.87 kg)
- AC Input Connections:. 5.0’ (1.5 m) AWG 16
- DC Output Connections: 6.0’ (1.8 m) AWG 10
Electrical Specifications:
- Absorption Voltage:
- 14.40 VDC
- 16.80 VDC
- 19.20 VDC
- Float Voltage at no Load:
- 13.56 VDC
- 15.82 VDC
- 18.08 VDC
- Maximum Output Voltage:
- 14.40 VDC
- 16.80 VDC
- 19.20 VDC
AC Input Specifications:
- AC Input Voltage: 120VAC, 50/60Hz or 230VAC, 50/60Hz -
- AC Input Current: 10A RMS fuse protected
Additional Notes:
- Ideal for maintaining performance and longevity of high-performance batteries.
- Not recommended to operate sensitive electronics (e.g., data loggers, computers) while charging due to potential high-voltage exposure.
- UPC: 692209011477
- Weight: 25.01
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
