XS Power SB1000-27 12V Super Capacitor Bank, Group 27, Max Power 8,000W, 1,000 Farad
We are a XS Power Authorized Dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • XS Power Battery
- • 12V Super Capacitor Bank
- • Owner's Manual
Extreme Power When Your System Demands It
Give high-demand electrical systems a serious performance boost with the XS Power SB1000-27 12V SuperBANK. Delivering up to 20,000 amps, 8,000 watts, and 1,000 farads, it provides rapid bursts of power to help support demanding electrical loads and maintain strong system performance. Its Group 27 design measures 12.09" × 6.65" × 8.31", combining massive power capability with a practical fit for performance applications.
Frequently Asked Questions (FAQ)
- • Why does my amplifier still clip after adding the SB1000-27?
The SB1000-27 can provide rapid bursts of current, but clipping can still occur if the amplifier is underpowered, the charging system is inadequate, or the electrical connections have excessive resistance. Check the alternator, battery, grounds, and power cables before assuming the SuperBANK is the problem.
- • Why does the SB1000-27 lose voltage quickly when the engine is turned off?
A SuperBANK behaves differently from a traditional battery. Its voltage can change rapidly as stored energy is used, so it should not be expected to provide long-term reserve power like a battery. Its primary advantage is delivering and accepting high-current bursts quickly.
- • Can a weak ground connection prevent the SB1000-27 from improving my audio system?
Yes. Poor grounding can create voltage loss between the battery, SuperBANK, amplifier, and chassis. Car-audio installers frequently identify grounding as a major source of electrical problems, so clean, secure, properly sized ground connections are essential.
- • Why does the SB1000-27 spark when I first connect it?
A discharged SuperBANK can initially draw a very large amount of current when connected directly to a charged electrical system. Use the manufacturer's controlled charging procedure rather than connecting a completely discharged unit directly to the battery.
- • Can I mount the SB1000-27 in the same location as a Group 27 battery?
Not necessarily. Although the SB1000-27 follows a Group 27 format, its actual dimensions are approximately 12.09 × 6.65 × 8.31 inches. Check the tray, hold-down system, terminal clearance, and cable routing before installation.
- • What should I check if my SB1000-27 seems to charge slowly?
Start by checking the vehicle's charging voltage, cable size, terminal tightness, and ground path. XS Power's installation guidance emphasizes clean connections and properly sized wiring because excessive resistance can interfere with effective charging.
- • Is it safe to handle the SB1000-27 after the vehicle has been switched off?
Not automatically. The SuperBANK can retain a dangerous electrical charge after the vehicle is shut down. Always verify with a properly calibrated meter that it has been discharged before touching or removing the terminals.
- • Why does my SB1000-27 get unusually warm during heavy use?
Heat can result from an installation or operating condition outside the specified range. Keep the SuperBANK away from major heat sources and provide suitable ventilation, especially in applications involving frequent cycling. Its specified operating temperature range is -40°F to 150°F.
- • Can loose M6 terminals cause intermittent power problems?
Yes. A loose terminal connection can introduce resistance and create unstable electrical performance, particularly when a high-current audio system demands power. The SB1000-27 includes M6 terminal hardware, so make sure the connections are properly secured and inspected periodically.
- • Can water or moisture damage the SB1000-27 during an off-road installation?
It should be protected from direct water splashes and spray. XS Power recommends avoiding direct exposure to water and corrosive environments and using an anti-oxidation treatment on terminal connections to help maintain reliable performance.
- Capacitance : 1000 Farad
- Digital Monitor : No
Features:
- Operating Voltage: 12.0V - 16.2V
- Operating Temperature: -40 - 150
- Capacitance: 1000F
- Watt Hours: 36.4Wh
- Max Amps: 20,000A
- Weight Lbs. : 22
- Weight Kgs. : 9.98
- Length : 12.09 in
- Height : 8.31 in
- Width : 6.65 in
- UPC: 692209053132
- Weight: 15
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
