- Diameter : 10 Inch
- Maximum Power : 1600 Watts
- Sensitivity : 82.3 dB
- Peak Power Handling : 1600 Watts
- Number of Voice Coils : Dual
- Mounting Depth : 7.34 Inches
- RMS Power Handling : 800 Watts
What's Inside?
- 1 10" ST Series Dual 2 Ohm Car Subwoofer
Features:
- 10 Inch Dual 2-ohm High Performance High Output Subwoofer
- 1600W Max / 800W RMS Power Handling
- Laminated Black Ribbed Design Pattern on Treated Semi-Pressed Cone
- Heavy Industrial Strength Textured Basket Frame
- Elevated Motor Structure Cooling Design
- Oversized Polished Black Chrome Finished Terminals
- Klippel DA Optimized Motor and Suspension Symmetry
- Dual Mirror-Imaged Oversized Spider
Specifications:
- 10” Dual 2-ohm/4-ohm High-Powered Subwoofer
- 800W RMS / 1600W MAX Power Handling
- Nominal Impedance (ohms) N/A
- Xmax - Inch(mm) 16.4
- Fs-Free Air Resonance (Hz) 33.0
- Vas (Liter) 17.4
- Qts 0.49
- Qes 0.58
- Qms 3.3
- Re (Ω)[series] 3.3
- Sd (cm²) 0.033
- Cms (mm/N) 0.115
- Mms (g) 200.0
- BL (T*M) 15.4
- SPL (db) 82.3
- Pwr (W) NOM/MAX 800/1600
- Mounting Depth 7.34″(186.5mm)
- Total Diameter 10.29″ (261.5mm)
- Mounting Diameter (inch/mm) 9.31″(236.5mm)
- Screw Hole Diameter 0.216″(5.5mm)
- Displacement (ft3/L) 0.081 ft3(2.3L)
- UPC: 847169019722
- Weight: 10
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
