XS Power SB75-30Q 12V Super Capacitor Bank, Group 30Q, Max Power 600W, 75 Farad
We are a XS Power authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 12V Super Capacitor Bank
- • Owner's Manual
High-Performance Features
The XS Power SB75-30Q is a 12V super capacitor bank designed for Group 30Q setups, offering a significant 75 Farad capacitance and a maximum power output of 600W. This capacitor bank is tailored for efficient power delivery, making it an ideal choice for various 12V electrical systems.
Frequently Asked Questions (FAQ)
- • Can the XS Power SB75-30Q replace my vehicle’s main battery?
No. The SB75-30Q is designed as a supercapacitor bank to work alongside a battery, helping provide rapid current during electrical demand spikes. It should not be treated as a direct replacement for a conventional starting or deep-cycle battery.
- • Why does my voltage still drop even after installing the SB75-30Q?
A SuperBANK can help stabilize voltage during short-duration current demands, but it cannot compensate for an undersized battery, inadequate alternator output, poor grounding, or wiring that cannot handle the system's load. Check the entire charging and electrical system rather than relying on the capacitor alone.
- • Do I need to charge the SB75-30Q before connecting it?
Yes, proper charging is important. Avoid connecting a completely discharged supercapacitor directly across a battery without following the manufacturer's charging procedure. A controlled initial charge helps prevent an excessive inrush current.
- • Is the SB75-30Q suitable for a 12V car audio system?
Yes, provided the electrical system is compatible with its operating range and power requirements. The SB75-30Q is intended for 12V applications and is rated for up to 600W.
- • What should I do if the SB75-30Q gets unusually hot?
First, stop operation and inspect the installation. Excessive heat can indicate incorrect wiring, excessive current, a poor connection, or an application outside the component's intended conditions. Check the terminals and charging voltage before putting the system back into service.
- • Why are my SB75-30Q terminal connections becoming loose?
Vibration can cause electrical connections to loosen, especially in automotive and powersports installations. The SB75-30Q uses M6 terminals, so make sure the appropriate hardware is used and that connections are securely tightened without damaging the terminals.
- • Will the SB75-30Q fit anywhere a Group 30 battery fits?
Not automatically. Although it uses a Group 30/30L case configuration, you still need to compare the actual mounting space and terminal orientation. Its listed dimensions are approximately 6.57 × 4.97 × 6.58 inches.
- • Why does my amplifier still cause lights to dim with the SB75-30Q installed?
The SB75-30Q can assist with short power-demand spikes, but persistent light dimming may indicate a larger charging-system problem. Inspect the battery, alternator, grounds, positive wiring, and amplifier power requirements before assuming the SuperBANK is defective.
- • Can I install the SB75-30Q in a high-vibration powersports vehicle?
It can be used in powersports applications, but the mounting and connections need to be secure. XS Power lists the SB75-30Q within its Q-case SuperBANK range for powersports applications.
- • How much power can the XS Power SB75-30Q actually handle?
The SB75-30Q is specified at 75 farads, with a 600W maximum power rating and up to 1,500A maximum current. These ratings describe the SuperBANK's electrical capability; they do not mean it can continuously supply 1,500A to a vehicle or amplifier.
Features:
- Length – 6.57 in
- Height – 6.58 in
- Width – 4.97 in
- Operating Voltage: 12.0V - 15V
- Operating Temperature: -40 - 150
- Max Power – 600W
- Max Amps – 1,500A
- Watt Hours – 4.08Wh
- Farads – 75F
- CA(5s) – 330A
- CCA(5s) – 290A
- UPC: 692209053699
- Weight: 2
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
